JVA ELECTRIC FENCE SYSTEMS
28
Installation Programming Options
7.6.18 Relay Functions
All relays can be set to any of the available
functions (user assignable).
Relay 1 is (21x#)
Relay 2 is (22x#), etc.
The modes are explained in the table opposite.
The defaults for the Z114 are:
NOTE: Optional extra relays can be retro-
tted. Contact your nearest JVA service
centre for details.
Value (x) Mode
0 Fence 1
1 Fence 1 or off
2 Armed 1
3 Fence 2
4 Fence 2 or off
5 Armed 2
6
7 General
8 Siren
9 Strobe
10 AC Fail
11 Low / Bad Battery
12 Tamper
13 Strobe 2
14 Gate 1 or 2
15 Siren caused by Gate
1 or 2
16 Armed in Low Power
Mode
17 Group Armed Note 3
18 Group General
Relay Function Values
Notes:
1. The siren and strobe switched 12V outputs
can be used to drive external buffer relays.
2. Group relay functions are only operable
on the group master.
7.6.17 Auto Re-arm Time (20x#)
This option sets the time which must elapse
alarm has timed out (gone completely through
its cycles without being turned off).
If an event occurs (such as a low fence voltage)
which triggers the siren, any other events which
would otherwise trigger the siren (such as a
gate alarm) will be ignored while the siren is
has passed.
If this time is set to less than the Siren Off Time,
the number of Siren Cycles will be reduced.
Value Missed Pulses
0 0 Seconds (immediate)
1 30 Seconds
2 1 Minutes
3 2 Minutes
4 3 Minutes
5 4 Minutes
6 5 Minutes
7 6 Minutes
8 7 Minutes
9 Disabled – Do not auto
rearm
Auto Re-Arm Time Values
