JVA ELECTRIC FENCE SYSTEMS
6
Specications
3. SPECIFICATIONS
Specication Name Specication
Energizer Output Voltage 9.5kV peak no load
Peak Output Energy 14 Joules at 200 Ohms
Pulse Rate Locked at 0.8 Hz
12v Dc Power Consumption Energizer On – 1.40A Average, 2.0A peak
Energizer Off – 28mA (40mA with keypad)
Not including keypad or auxiliary power
Ac Power Input
Battery Charger Output Float voltage 14V, 1.1A, short circuit and reverse
polarity protection
Siren and Strobe Outputs
at 30W (combined)
Enclosure IP4x ABS plastic
Size 303mm (H) x 223mm (W) x 122mm (D)
Weight – packed, no battery 3.1 kg
switching off, and to wait for at least 10 minutes before opening the case.
that the energizer be turned off and an intentional short circuit be placed from
the fence live wires to earth.
WARNING
