(No.YA394)3-3
USING P.W. BOARD & REMOTE CONTROL UNIT
EXPLODED VIEW PARTS LIST -1
P.W.B ASS'Y AV-2106TE AV-21T16 AV-21T16/L
MAIN P.W.B SCG-1528A-H2 SCG-1526A-H2 SCG-1527A-H2
REMOTE CONTROL UNIT RM-C360GY-1H ←←
Ref.No. Part No. Part Name Description Local
V01 A51LZM10X06AN25 PICTURE TUBE(ITC) Inc.DEF YOKE, PC MAGNET AV-2106TE,AV-21T16
V01 A51LZM10X06AS PICTURE TUBE Inc.DEF YOKE, PC MAGNET AV-21T16L
L01 QQW0006-001 DEG COIL
T522 QQH0170-001 FB TRANSF
1 GG40040-001A-H JVC MARK
2 GG30088-001B-H LED LENS
11 QYSBSFG4016ZA TAP SCREW M4 x 16mm(x4)
12 QYSBSF3010ZA TAP SCREW M3 x 10mm
13 QYSBSF4012ZA TAP SCREW M4 x 12mm
14 GG10265-007A-H REAR COVER
15 CM47005-A01-H POWER CORD CLAMP
16 QMPR340-165-K2 POWER CORD 1.65m BLACK AV-2106TE,AV-21T16,AV-21T16L
17 A48457-3-H SPRING
18 WJY0008-006A-E BRAIDED ASS'Y
19 CM36623-003-H CHASSIS RAIL (x2)
20 QYSBSF4012ZA TAP SCREW M4 x 12mm(x2)
21 QAS0054-001 SPEAKER SP01
22 GG40044-001A-M SIRIM LABEL AV-21T16L
30 SCG-1528A-H2 MAIN PWB AV-2106TE
30 SCG-1526A-H2 MAIN PWB AV-21T16
30 SCG-1527A-H2 MAIN PWB AV-21T16L
100 GG10269-003A-H FRONT CABINET ASS'Y Inc.101,102,103
101 GG30089-001A-H POWER KNOB
102 CM35235-003-H SPRING
103 GG20056-001A-H CONTROL KNOB
To Next Page
