Connecting a Guitar
You can connect a guitar to the unit directly through the GUITAR IN socket on the top
panel.
1. Connect your guitar to the GUITAR IN socket with a 6.5 mm connecter.
2. Turn the GUITAR VOL. dial to adjust the volume of the guitar.
Charging from the USB Charging Port
The CHARGING OUT 5V 2.1A socket is designed only for charging mobile devices
(e.g. MP3 player, mobile phone, etc.). It supplies 5V DC at a charging current of up to 2100
mA (2.1 A).
Use a USB cable (not included) to connect mobile device to the CHARGING OUT 5V
2.1A Socket of the unit and the mobile device will start charging.
2.1
LIGHT
MIC IN GUITAR IN LINE IN
EQ
VOL
BO OST E R
USB PLAYBACK CHARGE OUT
MIC ECHO VOL .
GUITAR VOL .
MIC VOL .
GUITAR IN
Top View of the Main Unit
2.1
LIGHT
MIC IN GUITAR IN LINE IN
EQ
VOL
BO OST E R
USB PLAYBACK CHARGE OUT
MIC ECHO VOL .
GUITAR VOL .
MIC VOL .
2.1
CHARGE OUT
Top View of the Main Unit
Guitar
(connect with a 6.5 mm connecter)
ONLY use the CHARGING OUT 5V 2.1A to charge small mobile devices. NEVER use this port for
any other purpose.
