7
GB
Product Overview
Top View
1. NFC Sensor
2. Bluetooth® Button
3. MIC VOL. Dial
4. MIC ECHO VOL. Dial
5. BOOSTER Button
6. MIC IN Socket
7. GUITAR IN Socket
8. LINE IN Socket
9. USB PLAYBACK 5V 0.5A Socket
10. CHARGING OUT 5V 2.1A Socket
11. STEREO CHAIN Button
12. EQ Button
13. TREBLE/BASS Button
14. LIGHT Dial/Button
15. GUITAR VOL. +/– Dial
16. VOL+/– Dial (If the unit is switched
o while the volume level is less
than 5 or over 25, the default
volume level will be restored the
next time the unit is switched on)
17. Button
18. SOURCE Button
19.
Button
20.
Play/Pause Button
21. Button
2.1
LIGHT
MIC IN GUITAR IN LINE IN
EQ
VOL
B OOS TE R
USB PLAYBACK CHARGE OUT
MIC ECHO VOL .
GUITAR VOL .
MIC VOL .
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
XS-D528BE_IB_Final180515V1.indd 7 15/5/2018 1:51 PM
