A-B Repeat
1 While playing, display the on-screen bar with the pull-
down menu.
2 Select .
3 Display the pop-up window.
4 Select “A-B”.
5 Select the start point (A).
• After selecting the starting point (A), you can search for
the end point using ¡ .
6 Select the end point (B).
To cancel A-B Repeat, repeat steps 1 to 3 , and select “OFF”
in step 4 .
To erase the on-screen bar
Time Search
You can move to a particular point by specifying the elapsed
playing time from the beginning.
1 While playing (without PBC for SVCD/VCD), display
the on-screen bar with the pull-down menu.
• Except for DVD: Time Search can be used before
starting playback.
2 Select .
3 Display the pop-up window.
4 Enter the time.
You can specify the time in hours/minutes/seconds.
• It is always required to enter the hour digit (even “0”
hour), but it is not required to enter trailing zeros (the
last two digits in the examples above).
• To correct a misentry,
press cursor 2 to erase the last
entry.
5 Finish the setting.
To erase the on-screen bar
A-B Repeat starts. The selected
portion plays repeatedly.
OFF
1/3
1/3 1/3
TIME
TITLE 14
TOTAL 1:25:58
CHAP 23
DVD-VIDEO
TITLE 2
TIME OFF CHAP. 1/31/ 3 1/1
TOTAL 1:01:58
CHAP 3
OFF
DISC 1
Dolby D
3/2.1ch
OFF
1/3
1/3 1/3
TIME
TITLE 14
TOTAL 1:25:58
CHAP 23
DVD-VIDEO
TITLE 2
TIME OFF CHAP. 1/31/ 3 1/1
TOTAL 1:01:58
CHAP 3
A–B
DISC 1
Dolby D
3/2.1ch
ENTER
OFF
1/3
TIME
TITLE 14
C
H
DVD-VIDEO
TITLE 2
TIME A- CHAP. 1/3
C
DISC 1
Dolby D
3/2.1ch
ENTER
ON
SCREEN
Examples:
To move to a point of 1 (hours):
02 (minutes): 00 (seconds), press
1, 0, 2, 0, then 0.
To move to a point of 54
(minutes): 00 (seconds), press 0,
5, 4, 0, then 0.
The System starts playing from the
specified time.
TIME _ : _ _ : _ _
OFF
1/3
1/3 1/3
TIME
TITLE 14
TOTAL 1:25:58
CHAP 23
DVD-VIDEO
TITLE 2
TIME OFF CHAP. 1/31/ 3 1/1
TOTAL 1:01:58
CHAP 3
DISC 1
Dolby D
3/2.1ch
123
456
789
10 0 +10
ENTER
ON
SCREEN
