JVC CA-EX90 - Specifications

50 CA-EX90
Amplifier/tuner (RX-EX90)
Output Power 20 watts per channel, min. RMS, both channels
driven, into 6 ohms from 70 Hz to 20 kHz, with
no more than 0.9% total harmonic distortion.
Total Harmonic Distortion (6 ohms, 1kHz) 0.08% at 14 watts output (* Measured by JVC
Audio Analysis System)
Audio Input Sensitivity/Impedance (1 kHz)
CD, MD 260 mV/49 kohms
TAPE 290 mV/54 kohms
AUX 370 mV/49 kohms
Audio output level/Impedance (1 kHz)
TAPE, MD 210 mV/400 ohms
SUB-WOOFER OUT 1.8 V/1 kohm
Speaker terminals
Impedance 6 – 16 ohms
Tuner Section
FM Tuner Tuning Range 87.5 – 108.0 MHz
AM Tuner Tuning Range 530 – 1,710 kHz
General
Dimensions 200 × 80 × 323.4 mm (W/H/D)
(7-7/8 × 3-3/16 × 12-3/4 inches)
Mass 3.3 kg (7.3 lbs)
Power Specifications
Power Requirements AC 120 V
, 60 Hz
Power Consumption 48 watts (at operation)
13 watts (in standby mode)
Subwoofer amplifier (ME-EX90)
Output Power 30 watts per channel, min. RMS, both channels
driven, into 3 ohms at 70 Hz with no more than
0.9% total harmonic distortion.
Input Sensitivity/Impedance (70 Hz)
SUB-WOOFER IN 670 mV/47 kohms
Speaker terminals
Impedance 3 – 16 ohms
General
Dimensions 200 x 80 x 323.4 mm (W/H/D)
(7-7/8 × 3-3/16 × 12-3/4 inches)
Mass 3.2 kg (7.1 lbs)
Power Specifications
Power Requirements AC 120 V
, 60 Hz
Power Consumption 54 watts (at operation)
8.6 watts (in standby mode)
Specifications
