JVC CA-NXG9

67
Specifications
Amplifier section—CA-NXG9/CA-NXG5 (NX-G5)
Output Power:
CA-NXG9:
MAIN SPEAKERS 180 W (90 W + 90 W) at 3 Ω
(10% THD)
SUBWOOFER 160 W at 4 Ω (10% THD)
CA-NXG5: 40 W (20 W + 20 W) at 4 Ω
(10% THD)
Audio Input: AUDIO IN:
Stereo min. (∅ 3.5 mm)
500 mV/47 kΩ (at “AUDIO LVL3”)
250 mV/47 kΩ (at “AUDIO LVL2”)
125 mV/47 kΩ (at “AUDIO LVL1”)
Digital Input/Output:
OPTICAL DIGITAL OUTPUT (output only):
–21 dBm to –15 dBm (660 nm ±30 nm)
Bluetooth ADPT
VIDEO/AUDIO PLAY USB 1 (input only)
AUDIO REC/PLAY USB 2
HDMI MONITOR OUT (output only)
VIDEO OUT:
Color system: NTSC/PAL (interlaced/
progressive)
VIDEO (Composite): 1 V(p-p)/75 Ω
COMPONENT: (Y) 1 V(p-p)/75 Ω
(P
B/PR) 0.7 V(p-p)/75 Ω
HDMI MONITOR OUT: 480p/576p/720p/1080i/1080p
Speaker impedance:
CA-NXG9:
MAIN SPEAKERS: 3 Ω – 16 Ω
SUBWOOFER: 4 Ω – 16 Ω
CA-NXG5: 4 Ω – 16 Ω
Tuner section
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range:
531 kHz – 1 710 kHz (at 9 kHz)
530 kHz – 1 710 kHz (at 10 kHz)
For Saudi Arabia: 531 kHz – 1 602 kHz (at 9 kHz)
530 kHz – 1 600 kHz (at 10 kHz)
Disc player section
Region codes: Middle East: 2 / South East Asia: 3 /
Central and South America,
Australia: 4
Playable disc:
• DVD Video/CD/VCD/SVCD
• CD-R/CD-RW (CD/SVCD/VCD/MP3/WMA/
WAV/JPEG/MPEG-1/MPEG-2/ASF/DivX format)
• DVD-R/-RW (DVD-VR/DVD Video/MP3/WMA/
WAV/JPEG/MPEG-1/MPEG-2/ASF/DivX format)
• +R (DVD Video/MP3/WMA/WAV/JPEG/MPEG-
1/MPEG-2/ASF/DivX format)
• +RW (MP3/WMA/WAV/JPEG/MPEG-1/MPEG-
2/ASF/DivX format)
• DVD-ROM (MP3/WMA/WAV format)
Dynamic range: 80 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
USB section
Playable files:
USB1: MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/ASF/DivX format
USB2: MP3/WMA/WAV format
Recording format: MP3/WMA format
USB specification: Compatible with USB 2.0 Full Speed
Compatible device: Mass storage class
Compatible system: FAT16, FAT32
Bus power supply: DC 5 V
500 mA
Bluetooth section
Version: Bluetooth ver. 2.0 + EDR Class 1/Class 2
Compatible Bluetooth profile: A2DP, AVRCP
Communication format: 2.4 GHz FHSS
HDMI section
Output power: DC 5 V 55 mA
General—CA-NXG9
Power requirements: AC 220 V /AC 230 V – AC
240 V,
(adjustable with the
voltage selector), 50 Hz / 60 Hz
For Saudi Arabia: AC 220 V
, 50 Hz / 60 Hz
For Australia: AC 240 V
, 50 Hz
Power consumption: 85 W (at operation) / 13 W (at
standby) / 1.3 W or less (at ECO mode)
Dimensions (approx.):
250 mm × 158 mm × 259 mm (W/H/D)
Mass (approx.): 5.0 kg
General—CA-NXG5 (NX-G5)
Power requirements: AC 110 V – AC 240 V ,
50 Hz / 60 Hz
For Australia: AC 240 V
, 50 Hz
Power consumption: 40 W (at operation) / 3.0 W (at
standby) / 1.0 W or less (at ECO mode)
Dimensions (approx.):
250 mm × 158 mm × 259 mm (W/H/D)
Mass (approx.): 3.0 kg
Speakers—SP-NXG5 (NX-G5)
Type: 2-way 2-speaker bass reflex type
(Magnetically shielded)
Speaker units: Tweeter: 4 cm cone x 1
Woofer: 12 cm cone x 1
Impedance: 4 Ω
Power handling capacity: 20 W
Frequency Range: 50 Hz - 28 000 Hz
Dimensions (approx.):
155 mm × 250 mm × 168 mm (W/H/D)
Mass (approx.): 2.1 kg each
Supplied Accessories
See page 4.
Design and specifications are subject to change
without notice.
