7
Front panel
From the USB mass storage class device
To the headphones
From the digital audio player
To the microphones (only for CA-NXG9)
See page 44.
When connecting a digital audio player
• See page 14 for audio input level.
When connecting a USB mass storage class device
• When connecting with a USB cable, use the USB 2.0
cable whose length is less than 1 m.
• You can connect a USB mass storage class device
such as a USB flash memory device, hard disk drive,
multimedia card reader, etc. to this System.
You can select the video output to match it to the color
system of your TV (NTSC or PAL).
• If you connect a progressive TV through the
COMPONENT cords or the HDMI cable, you can
enjoy a high quality picture by selecting progressive
scanning mode.
• You can change the setting only while playback is
stopped.
1
2
From the Bluetooth adapter
See page 38.
When an HDMI cable is connected
AUTO
The System automatically emits the
video signal to get the best picture
quality on your TV.
PAL 576P /
PAL 720P /
PAL 1080I /
PAL 1080P
For a PAL TV.
P: Progressive
I: Interlaced
NTSC 480P /
NTSC 720P /
NTSC 1080I /
NTSC 1080P
For a NTSC TV.
P: Progressive
I: Interlaced
When an HDMI cable is not connected
PAL 576I
PAL 576P
For a PAL TV. Select “PAL 576P” if
you connect a progressive TV through
the COMPONENT jacks.
NTSC 480I
NTSC 480P
For an NTSC TV. Select “NTSC
480P” if you connect a progressive TV
through the COMPONENT jacks.
Changing the Color System and Scanning Mode
Stereo mini plug
(not supplied)
From audio output (or headphone
out, etc.)
USB cable (not
supplied)
text_EN_NXG9G5.indb 7text_EN_NXG9G5.indb 7 08.8.5 10:52:00 AM08.8.5 10:52:00 AM
To Next Page
