JVC D-ILA DLA-HD1-BC User Manual

1-8 (No.PA023)
2.3.2 Operation button & LED location
2.3.3 Input / output terminal location
TOP SIDE
REAR SIDE
Light on (Red):
Warning mode
Light on/Blinking (Orange):
Lamp warning
To turn on/off the power
To hide the image temporarily
To return to the previous menu
To switch input
To display the menu
Light on (Red):
Standb y mode
Light on (Green):
During projection
Blinking (Green):
Image is temporarily hidden
Blinking (Red):
Cool Down mode
To select or confirm
AC POWER INPUT Terminal
S-VIDEO
MDMI 2 MDMI 1 RS-232C
COMPONENT
VIDEO
SYNC
Y CB/PB CR/PR
S-VIDEO
Terminal
COMPOSITE VIDEO Terminal
RS-232C Terminal
COMPONENT
VIDEO Terminal
HDMI Terminal
