JVC DT-E17L4G - Available Signals

29
Available signals
The following signals are available for this monitor.
Video signals
No. Signal name
Signal format shown in
the status display
(☞ page 12)*
5
Input terminal
VIDEO analog COMPO. analog RGB
E.AUDIO *
1
HD/SD SDI
HDMI
1 NTSC NTSC √ — — — —
2 NTSC 4.43 N 4.43 √ — — — —
3 PAL-M PAL-M √ — — — —
4 PAL60 PAL60 √ — — — —
5 PAL PAL √ — — — —
6 PAL-N PAL-N √ — — — —
7 SECAM SECAM √ — — — —
8 B/W50 B/W50 √ — — — —
9 B/W60 B/W60 √ — — — —
10 480/60i 480/60i — √ — — √
11 480/59.94i 480/59.94i — √ — √ √
12 576/50i 576/50i — √ — √ √
13 480/60p 480/60p — √ — — √
14 480/59.94p 480/60p — √ — — √
15 576/50p 576/50p — √ — — √
16 640*480/60p 640*480/60p — — √ — √
17 640*480/59.94p 640*480/60p — — √ — √
18 720/60p 720/60p — √ — √ √
19 720/59.94p 720/59.94p — √ — √ √
20 720/50p 720/50p — √ — √ √
21 720/30p 720/30p — — — √ —
22 720/29.97p 720/29.97p — — — √ —
23 720/25p 720/25p — — — √ —
24 720/24p 720/24p — — — √ —
25 720/23.98p 720/23.98p — — — √ —
26 1080/60i 1080/60i — √ — √ √
27 1080/59.94i 1080/59.94i — √ — √ √
28 1035/60i 1035/60i — — — √ √
29 1035/59.94i 1035/59.94i — — — √ √
30 1080/50i 1080/50i — √ — √ √
31 1080/60p 1080/60p — √ √ — √
32 1080/59.94p 1080/60p — √ √ — √
33 1080/50p 1080/50p — √ √ — √
34 1080/30p 1080/30p — — — √ √
35 1080/29.97p 1080/29.97p — — — √ √
36 1080/25p 1080/25p — — — √ √
37 1080/24p 1080/24p — — — √ √
38 1080/23.98p 1080/23.98p — — — √ √
39 1080/30PsF 1080/30psf — — — √*
2
—
40 1080/29.97PsF 1080/29.97psf — — — √*
3
—
41 1080/25PsF 1080/25psf — — — √*
4
—
42 1080/24PsF 1080/24psf — — — √ —
43 1080/23.98PsF 1080/23.98psf — — — √ —
√: Acceptable
—: Not acceptable
*
1
Compatible with EMBEDDED AUDIO signals.
*
2
The signal is recognized as 1080/60i, and the status is displayed as “1080/60i.”
*
3
The signal is recognized as 1080/59.94i, and the status is displayed as “1080/59.94i.”
*
4
The signal is recognized as 1080/50i, and the status is displayed as “1080/50i.”
*
5
For signal formats other than E.Audio HD/SD SDI input, **/59.94, **/29.97, and **/23.98 will be displayed as **/60, **/30, and **/24 respectively.
●
HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
● HDCP stands for High-bandwidth Digital Content Protection, a copy protection technology of high reliability licensed by Digital Content
Protection, LLC.
