JVC DX-U10A User Manual

3-29
AMP board(DX-U8)
Block No. [0][3]
R4606 QRE141J-561Y C RESISTOR 560 Ω 1/4W J
R4607 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4608 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
 R4609 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R4610 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4611 QRE141J-561Y C RESISTOR 560
Ω 1/4W J
 R4701 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R4702 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R4703 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R4704 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R4705 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4706 QRE141J-561Y C RESISTOR 560
Ω 1/4W J
R4707 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4708 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
 R4709 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R4710 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4711 QRE141J-561Y C RESISTOR 560
Ω 1/4W J
R4801 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4802 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R4811 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4812 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R4901 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4902 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4903 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4904 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4905 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4906 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
L3401 QQLZ035-R39 COIL 0.39uH
L3401 QQLZ042-R45 COIL 0.45uH 10UH
L3501 QQLZ035-R39 COIL 0.39uH
L3501 QQLZ042-R45 COIL 0.45uH 10UH
L3601 QQLZ035-R39 COIL 0.39uH
L3601 QQLZ042-R45 COIL 0.45uH 10UH
L4101 QQLZ035-R39 COIL 0.39uH
L4101 QQLZ042-R45 COIL 0.45uH 10UH
L4201 QQLZ035-R39 COIL 0.39uH
L4201 QQLZ042-R45 COIL 0.45uH 10UH
L4601 QQLZ035-R39 COIL 0.39uH
L4601 QQLZ042-R45 COIL 0.45uH 10UH
L4701 QQLZ035-R39 COIL 0.39uH
L4701 QQLZ042-R45 COIL 0.45uH 10UH
CN201 QGA3901C1-10 CONNECTOR W-B (1-10)
CN203 QGB2510K2-16 CONNECTOR B-B (1-16)
CN204 QGB2510J1-10 CONNECTOR B-B (1-10)
CN205 QGB2510J1-16 CONNECTOR B-B (1-16)
CN207 QGD2504C1-03Z CONNECTOR (1-3)
CN301 QGB2510K2-10 CONNECTOR B-B (1-10)
CN302 QGF1205C2-15 CONNECTOR FFC/FPC (1-15)
CN302 QGF1208C1-15 CONNECTOR FFC/FPC (1-15) 10UH
CN304 QGA2501F1-03 CONNECTOR W-B (1-3)
CN305 QGD2504C1-05Z CONNECTOR (1-5)
CN306 QGD2504C1-05Z CONNECTOR (1-5)
CN403 QGF1205F2-07 CONNECTOR FFC/FPC (1-7)
CN403 QGF1208F1-07 CONNECTOR FFC/FPC (1-7) 10UH
CN404 QGB2510K2-16 CONNECTOR B-B (1-16)
FW201 QUM15A-18DGZ4-E WIRE
FW301 QUM156-27DGZ4-E CONNECTOR
FW401 QUM156-12Z4Z4-E FLAT WIRE
PP201 QNZ0104-001 POST PIN
PP203 QZW0112-001 WIRE CLAMP
Z2001 QNG0003-001Z FUSE CLIP
Z2002 QNG0003-001Z FUSE CLIP
Z2003 QNG0003-001Z FUSE CLIP
Z2004 QNG0003-001Z FUSE CLIP
Z2009 QNG0003-001Z FUSE CLIP
Z2010 QNG0003-001Z FUSE CLIP
Z2011 QNG0003-001Z FUSE CLIP
Z2012 QNG0003-001Z FUSE CLIP
Z2013 QNG0003-001Z FUSE CLIP
Z2014 QNG0003-001Z FUSE CLIP
Z2015 QNG0003-001Z FUSE CLIP
Z2016 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC302 KIA7812API IC
 IC303 KIA78D06PI-U/P IC
 IC304 KIA7809API IC
 IC305 PQ050RDC2SZF IC
 IC306 KIA278R09PI IC
 IC307 STK433-240A-E IC
 IC401 STK416-130-E IC
 Q2300 KTA1046/Y/ TRANSISTOR
Q2301 KTC3203/OY/-T TRANSISTOR
Q3401 KTC3199/GL/-T TRANSISTOR
Q3501 KTC3199/GL/-T TRANSISTOR
Q3601 KTC3199/GL/-T TRANSISTOR
Q3901 KTA1271/OY/-T TRANSISTOR
Q3902 KTC3199/GL/-T TRANSISTOR
Q4601 KTC3199/GL/-T TRANSISTOR
Q4701 KTC3199/GL/-T TRANSISTOR
Q4901 KTC3200/GL/-T TRANSISTOR
Q4902 KTA1268/GL/-T TRANSISTOR
Q4903 KTC3199/GL/-T TRANSISTOR
Q4904 KTA1268/GL/-T TRANSISTOR
Q4951 KTC3199/GL/-T TRANSISTOR
 D2001 GBU803 BRIDGE DIODE
D2002 2A02-M DIODE
D2003 2A02-M DIODE
 D2101 GBU803 BRIDGE DIODE
 D2200 1N5402M-20 SI DIODE
 D2201 1N5402M-20 SI DIODE
 D2202 1N5402M-20 SI DIODE
 D2203 1N5402M-20 SI DIODE
D2312 MTZJ7.5B-T2 Z DIODE
D2314 MTZJ36A-T2 Z DIODE
D2315 1N4003S-T5 SI DIODE
D2317 1N4003S-T5 SI DIODE
D3401 1SS133-T2 SI DIODE
D3501 1SS133-T2 SI DIODE
D3601 1SS133-T2 SI DIODE
D3701 MTZJ6.2B-T2 Z DIODE
D3811 MTZJ11B-T2 Z DIODE
D3821 MTZJ11B-T2 Z DIODE
D3832 MTZJ6.8B-T2 Z DIODE
D3841 MTZJ13B-T2 Z DIODE
D4501 MTZJ18B-T2 Z DIODE
D4502 MTZJ18B-T2 Z DIODE
D4503 MTZJ36B-T2 Z DIODE
D4504 MTZJ36B-T2 Z DIODE
D4505 1N5402M-20 SI DIODE
D4506 1N5402M-20 SI DIODE
D4601 1SS133-T2 SI DIODE
D4701 1SS133-T2 SI DIODE
D4901 1SS133-T2 SI DIODE
D4951 1SS133-T2 SI DIODE
C2000 QEZ0581-478 E CAPACITOR 4700uF 63V M
C2004 QEZ0581-478 E CAPACITOR 4700uF 63V M
C2005 QFZ0228-104Z M CAPACITOR 0.1uF 250V M
C2006 QETM1VM-478 E CAPACITOR 4700uF 35V M
C2007 QFZ0228-104Z M CAPACITOR 0.1uF 250V M
C2008 QETM1VM-478 E CAPACITOR 4700uF 35V M
C2009 QFZ0228-104Z M CAPACITOR 0.1uF 250V M
C2010 QETN1VM-227Z E CAPACITOR 220uF 35V M
C2011 QETN1VM-227Z E CAPACITOR 220uF 35V M
C2115 QFZ0228-104Z M CAPACITOR 0.1uF 250V M
C2212 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2213 QETM1CM-688 E CAPACITOR 6800uF 16V M
C2214 QETM1VM-478 E CAPACITOR 4700uF 35V M
C2215 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2218 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2302 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2303 QETN1HM-226Z E CAPACITOR 22uF 50V M
C2304 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C2305 QETN1HM-106Z E CAPACITOR 10uF 50V M
C2316 QETM2AM-227 E CAPACITOR 220uF 100V M
