3-32
FL board
Block No. [0][5]
C4801 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4802 QTE1J46-106Z E CAPACITOR 10uF 63V
C4803 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4804 QTE1J46-106Z E CAPACITOR 10uF 63V
C4805 QCBB1HK-471Y C CAPACITOR 470pF 50V K
C4806 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4811 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4812 QTE1J46-106Z E CAPACITOR 10uF 63V
C4813 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C4901 QETN1HM-106Z E CAPACITOR 10uF 50V M
C4902 QETN1EM-476Z E CAPACITOR 47uF 25V M
C4903 QETN1HM-106Z E CAPACITOR 10uF 50V M
C4952 QCSB1HK-3R3Y C CAPACITOR 3.3pF 50V K
C4953 QETN1JM-107Z E CAPACITOR 100uF 63V M
C4954 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4955 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
R2000 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2001 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2002 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2003 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2200 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 R2300 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
R2301 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R2302 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R2305 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
 R2306 QRK126J-470X UNF C RESISTOR 47 Ω 1/2W J
R2307 QRK126J-470X UNF C RESISTOR 47
Ω 1/2W J
R2308 QRK126J-470X UNF C RESISTOR 47
Ω 1/2W J
R3701 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R3907 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4501 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R4502 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R4503 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
R4504 QRE141J-682Y C RESISTOR 6.8k
Ω 1/4W J
 R4505 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
 R4506 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R4507 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
 R4601 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R4602 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R4603 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R4604 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R4605 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4606 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
R4607 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4608 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
 R4609 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R4610 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4611 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
 R4701 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R4702 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R4703 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R4704 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R4705 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4706 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
R4707 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4708 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
 R4709 QRJ146J-221X UNF C RESISTOR 220 Ω 1/4W J
R4710 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4711 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
R4801 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4802 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R4803 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4804 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R4811 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4812 QRE141J-563Y C RESISTOR 56k
Ω 1/4W J
R4901 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4902 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4903 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4904 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4905 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R4906 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R4950 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
 R4951 QRZ0224-R22 EMIT RESISTOR 0.22 Ω
R4952 QRE141J-563Y C RESISTOR 56k Ω 1/4W J
 R4953 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
 R4954 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R4955 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
R4956 QRE141J-202Y C RESISTOR 2k Ω 1/4W J
R4957 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4958 QRE141J-562Y C RESISTOR 5.6k
Ω 1/4W J
 R4959 QRJ146J-181X UNF C RESISTOR 180 Ω 1/4W J
R4960 QRE141J-202Y C RESISTOR 2k
Ω 1/4W J
L4601 QQLZ035-R39 COIL 0.39uH
L4701 QQLZ035-R39 COIL 0.39uH
L4951 QQLZ035-R39 COIL 0.39uH
CN201 QGA3901C1-10 CONNECTOR W-B (1-10)
CN202 QGB2510K2-08 CONNECTOR B-B (1-8)
CN204 QGB2510J1-05 CONNECTOR B-B (1-5)
CN205 QGB2510J1-13 CONNECTOR B-B (1-13)
CN207 QGD2504C1-03Z CONNECTOR (1-3)
CN303 QGF1205C2-09 CONNECTOR FFC/FPC (1-9)
CN304 QGA2501F1-03 CONNECTOR W-B (1-3)
CN307 QGB2510K2-05 CONNECTOR B-B (1-5)
CN403 QGF1205F2-07 CONNECTOR FFC/FPC (1-7)
CN404 QGB2510K2-13 CONNECTOR B-B (1-13)
FW301 QUM156-27DGZ4-E CONNECTOR
PP201 QNZ0104-001 POST PIN
PP203 QZW0112-001 WIRE CLAMP
Z2001 QNG0003-001Z FUSE CLIP
Z2002 QNG0003-001Z FUSE CLIP
Z2003 QNG0003-001Z FUSE CLIP
Z2004 QNG0003-001Z FUSE CLIP
Z2009 QNG0003-001Z FUSE CLIP
Z2010 QNG0003-001Z FUSE CLIP
Z2011 QNG0003-001Z FUSE CLIP
Z2012 QNG0003-001Z FUSE CLIP
Z2013 QNG0003-001Z FUSE CLIP
Z2014 QNG0003-001Z FUSE CLIP
Z2015 QNG0003-001Z FUSE CLIP
Z2016 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
IC500 PT6324-HT FL DRIVER
IC510 GP1UM281XKVF IR DETECT UNIT
Q5011 KRC107M-T DIGI TRANSISTOR
Q5012 KRC107M-T DIGI TRANSISTOR
Q5013 KRC107M-T DIGI TRANSISTOR
Q5014 KRC107M-T DIGI TRANSISTOR
Q5500 KRC102M-T DIGI TRANSISTOR
D5004 SLI-343U8RC-T LED
D5005 SLI-343U8RC-T LED
D5006 SLR-343VC-T LED
D5500 SELU2E10C-P LED 10A,10US,
10UX,10UG,
10UN,8US,
8UX,8UG,
8UN,6US,
6UX,6UG,
6UN
D5500 SELT2E10C-S LED 10UH
D5501 SELU2E10C-P LED 10A,10US,
10UX,10UG,
10UN,8US,
8UX,8UG,
8UN,6US,
6UX,6UG,
6UN
D5501 SELT2E10C-S LED 10UH
D5502 SELU2E10C-P LED 10A,10US,
10UX,10UG,
10UN,8US,
8UX,8UG,
8UN,6US,
6UX,6UG,
6UN
 Symbol No. Part No. Part Name Description Local
