DVD loading board(Except DX-U6)
Block No. [0][8]
R334 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R335 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R336 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R337 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30k
Ω 1/16W D
R341 NRSA63D-512X MG RESISTOR 5.1k
Ω 1/16W D
R342 NRSA63D-222X MG RESISTOR 2.2k
Ω 1/16W D
R345 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R346 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R347 NRSA63J-203X MG RESISTOR 20k
Ω 1/16W J
R348 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R351 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R352 NRSA63J-105X MG RESISTOR 1M
Ω 1/16W J
R353 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R357 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R358 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R359 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R360 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R361 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R362 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R367 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R371 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R372 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R373 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R375 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R376 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R383 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R384 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R385 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R392 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R452 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R453 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R454 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R455 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R456 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R457 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R458 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R461 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R463 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R464 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R465 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R531 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R535 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R541 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R701 NRSA63J-2R2X MG RESISTOR 2.2
Ω 1/16W J
R704 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R705 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R714 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R715 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R716 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R718 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R719 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R721 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R723 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R724 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R725 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R727 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R728 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R731 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R732 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R741 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R742 NRSA63J-5R1X MG RESISTOR 5.1
Ω 1/16W J
R811 NRS181J-330X MG RESISTOR 33
Ω 1/8W J
R812 NRS181J-330X MG RESISTOR 33
Ω 1/8W J
R813 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R814 NRSA63J-153X MG RESISTOR 15k
Ω 1/16W J
R819 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R859 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R860 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R861 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
CN101 QGF0523F3-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN451 QGF1016F8-15W CONNECTOR FFC/FPC (1-15)
CN452 QGA2001F6-02X CONNECTOR W-B (1-2)
CN453 QGA2001F6-03X CONNECTOR W-B (1-3)
 Symbol No. Part No. Part Name Description Local
CN701 QGF1016F8-28W CONNECTOR FFC/FPC (1-28)
CN702 QGF1016F8-10W CONNECTOR FFC/FPC (1-10)
CN703 QGF1016F8-08W CONNECTOR FFC/FPC (1-8)
CN801 QGF1016F8-05W CONNECTOR FFC/FPC (1-5)
CN811 QGA2001F6-05X CONNECTOR W-B (1-5)
K101 NQR0502-001X FERRITE BEADS
K351 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K353 NQR0502-001X FERRITE BEADS
K354 NQR0022-002X FERRITE BEADS
K454 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K455 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K456 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K501 NQR0502-001X FERRITE BEADS
K720 NQR0022-002X FERRITE BEADS
K732 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K733 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K734 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K735 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K736 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K737 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K738 NQR0022-005X FERRITE BEADS
K741 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K744 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K748 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K749 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K750 NQR0022-002X FERRITE BEADS
K752 NQR0022-002X FERRITE BEADS
K754 NQR0022-002X FERRITE BEADS
K756 NQR0022-002X FERRITE BEADS
K758 NQR0022-002X FERRITE BEADS
K811 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
K812 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
TH301 NAD0025-103X N THERMISTOR 10k
Ω
X301 NAX0741-001X CRYSTAL 27.000MHz
X302 NAX0376-002X CRYSTAL
X451 NAX0248-001X C OSCILLATOR 8.000MHz
 Symbol No. Part No. Part Name Description Local
IC1 LB1641 IC
IC2 LB1641 IC
D1 MTZJ6.2A-T2 Z DIODE
C1 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C2 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C3 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C5 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C6 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
CN1 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN2 QGB2024K1-07S CONNECTOR B-B (1-7)
CN3 QGB2024J1-07S CONNECTOR B-B (1-7)
SW1 QSW0844-001 PUSH SWITCH
SW2 QSW0844-001 PUSH SWITCH
SW3 QSW0844-001 PUSH SWITCH
SW4 QSW0844-001 PUSH SWITCH
SW5 QSW0844-001 PUSH SWITCH
SW6 QSW0854-002 PUSH SW
SW8 QSW0923-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
