EN11
GETTING
STARTED
Camcorder
! Touch Sensor
# OK Button
$ MENU Button
% Power (1) Button
& SD Card Slot ( pg. 18)
( EXPORT Button
) AV Connector
* UPLOAD Button ( pg. 36)
+ PLAY/REC Button ( pg. 19, 20, 22, 23)
, Mode Switch [!, #]
- DIRECT DVD Button ( pg. 28)
INFO Button ( pg. 21)
. START/STOP Button ( pg. 19)
/ SNAPSHOT Button ( pg. 20)
0Zoom Lever [W 7, T] ( pg. 21)
Speaker Volume Control
1 Speaker
2 DC Connector
3 USB Connector ( pg. 27, 30)
4 Camera Sensor
5 LED Light ( pg. 21)
6 Lens Cover
7 Lens
8Stereo Microphone
9Stud Hole
: Tripod Mounting Socket ( pg. 17)
; Battery Release Button [BATT.] ( pg. 15)
Remote Control
Q Infrared Beam Transmitting Window
R ZOOM (T/W) Buttons (Zoom in/out)
S Up Button
T Skip Backward Button
U Left Button
V Back Button
W PLAYLIST Button
X START/STOP Button
Y S. SHOT (SNAPSHOT) Button
Z INFO Button
a Skip Forward Button
b PLAY/PAUSE/SET Button
c Right Button
d Next Button
e Down Button
f INDEX Button*
g DISP Button
* Each time you press INDEX, the screen
switches as shown below:
!mode:
Index Screen « Group Index Screen
#mode:
Index Screen «Date Index Screen
