JVC EX-A10 User Manual

45
Set the clock beforehand. (A page 15)
1 Slide the remote control
mode selector to
RECEIVER.
2 Press CLOCK/TIMER.
Display on the receiver
• If you accidentally pressed CLOCK/TIMER
twice or more, press CLOCK/TIMER
repeatedly until the display shown above is
displayed.
3 Press SET.
4 Set the starting time and ending
time with 2, 3 (cursor), and
then press SET.
Example:
Display on the receiver when setting the
starting time to 8:45
Display on the receiver when setting the
ending time to 9:45
• Press 2 or 3 (cursor) to select the value
and press SET to set the value.
• You can use the number buttons instead of
2 or 3 (cursor). Refer to “Using the
number buttons” (A page 15).
5 Press 2 or 3 (cursor) to select
“ONCE” or “WEEKLY”, and
then press SET.
ONCE The playback timer works once.
WEEKLY The playback timer works
weekly or every day.
6 Press 2 or 3 (cursor) to select
the desired day of the week, and
then press SET.
• Each time you press 2 or 3 (cursor), the
display changes as follows.
When “ONCE” is selected
When “WEEKLY” is selected
Using the playback timer
2/3
(cursor)
F AUDIO
CLOCK/
TIMER
SLEEP
CANCEL
SET
Number
buttons
Remote control
mode selector
(The playback timer works every day.)
(The playback timer
works Monday to
Saturday.)
(The playback timer
works Monday to
Friday.)
Timer
Timer
EXA10[B]-06.fm Page 45 Monday, August 8, 2005 5:01 PM

JVC EX-A10 Specifications

General

Impedance	6 Ω
RMS rated power	20 W
Equalizer	Yes
Volume control	Digital
Supported radio bands	AM, FM
Type	Home audio micro system
Speakers	2-Way, Bass-Reflex
Dimensions (WxDxH)	245 x 80 x 297 mm
USB 2.0 ports quantity	1

Weight and Dimensions

Weight	2700 g
Center speaker weight	3500 g
Center speaker dimensions (WxDxH)	143 x 243 x 257 mm
