JVC GR-DVM50 - 71 Controls Connectors; Default Chapter; Other Parts

EN71
Controls
1 Snapshot Mode Button
[SNAPSHOT MODE] .......................... Z pg. 26
2 Multi Screen Button
[MULTI SCREEN] ................................ Z pg. 27
3 Operation Switch [ , ] ................. Z pg. 15
4 •Power Zoom Lever [T/W] ................. Z pg. 20
•Speaker/Headphone Volume
Control [VOL.] ................................. Z pg. 42
5 START/STOP Button ............................ Z pg. 16
6 Snapshot Button [SNAPSHOT] ............ Z pg. 26
7 Back Light Button [BACK LIGHT] ........ Z pg. 38
8 OPEN/EJECT Switch ............................ Z pg. 11
9 Battery Release Switch
[BATT. RELEASE] ................................. Z pg. 9
0 •MENU/SET Dial [+, –, PUSH] ..... Z pg. 10, 28
•LCD Monitor/Viewfinder Brightness
Control ............................................ Z pg. 19
! Power Switch ..................................... Z pg. 15
@ Play/Pause Button [ 4 /6] ..................... Z pg. 42
# Rewind Button [ 2 ] ........................... Z pg. 42
$ Stop Button [5] .................................. Z pg. 42
% Fast-Forward Button [ 3 ] ................... Z pg. 42
^ Lock Button ........................................ Z pg. 15
& Diopter Adjustment Control ................ Z pg. 13
Connectors
The connectors * to ) are located beneath the cover.
* Digital Video Connector
[DV IN/OUT] (i.link*) ................... Z pg. 49, 51
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
( •Audio/Video Output Connector
[AV OUT] ........................................ Z pg. 46
• Headphones Connector [ ] ............ Z pg. 62
) Multi Connector
When attached to the Docking Station, this part is
connected.
Indicators
q Tally Lamp .......................................... Z pg. 16
w Power Lamp ....................................... Z pg. 16
Other Parts
e Camera Sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
r Lens Cover
Opens when the viewfinder is pulled out or the
LCD monitor is opened fully.
t Stereo Microphone ............................. Z pg. 62
y Viewfinder .......................................... Z pg. 13
u Remote Sensor .................................... Z pg. 52
i LCD Monitor ...................................... Z pg. 19
o Speaker .............................................. Z pg. 42
p Battery Pack Mount ............................ Z pg. 9
Q Grip Strap ........................................... Z pg. 13
W Stud Hole ........................................... Z pg. 46
E Tripod Mounting Socket ................ Z pg. 14, 46
