76 EN
SPECIFICATIONS
Camcorder
For General
Power supply : DC 6.3 V (Using AC Power Adapter/Charger)
DC 7.2 V (Using battery pack)
Power consumption
LCD monitor off, viewfinder on : Approx. 4.7 W
LCD monitor on, viewfinder off : Approx. 5.5 W
Dimensions (W x H x D) : 51 mm x 125 mm x 97 mm
(with the LCD monitor closed and the viewfinder pushed back in)
Weight : Approx. 500 g
(without cassette and battery)
Approx. 575 g
(incl. cassette and battery)
Operating temperature :0°C to 40°C
Operating humidity : 35% to 80%
Storage temperature : –20°C to 50°C
Pickup : 1/4" CCD (Progressive Scan)
Lens : F 1.8, f = 3.8 mm to 38 mm, 10:1 power zoom lens
Filter diameter : ø27 mm
LCD monitor : 2.5" diagonally measured, LCD panel/TFT active matrix system
Viewfinder : Electronic viewfinder with 0.44" colour LCD
Speaker : Monaural
For Digital Video Camera
Format : DV format (SD mode)
Signal format : PAL standard
Recording/Playback format : Video: Digital component recording
: Audio: PCM digital recording, 32 kHz 4-channel (12-bit),
48 kHz 2-channel (16-bit)
Cassette : Mini DV cassette
Tape speed : SP: 18.8 mm/s
LP: 12.5 mm/s
Maximum recording time : SP: 80 min.
(using 80 min. cassette) LP: 120 min.
For Connectors
Video output :1 V
(
p-p
)
, 75 Ω, analogue
Audio output : 300 mV (rms), 1 kΩ, analogue, stereo
DV Input/output : 4-pin, IEEE 1394 compliant
Headphone output : ø3.5 mm, stereo
To Next Page
