EN49
Controls
1 Video Light Switch [LIGHT OFF/AUTO/ON]
(GR-SXM470A/FXM270A/FX220A/
SXM27EA/SX22EA only) ....................... pg. 17
2 Stop Button [STOP] .............................. pg. 30
3 •Retake Rewind Button [RETAKE R]..... pg. 17
•Quick Review Button [ R] ............ pg. 17
•Rewind Button [R] ............................. pg. 30
4 Play/Pause Button ................................ pg. 30
5 •Retake Forward Button [RETAKE F] .... pg. 17
•Fast-Forward Button [F] ..................... pg. 30
6 •Fade/Wipe Button [FADE/WIPE] ........ pg. 19
•Counter Reset/Memory Button
[COUNTER R/M] .............................. pg. 31
7 Program AE Button [P. AE] .................... pg. 20
8 Digital Effect Button [DIGIFECT] .......... pg. 21
9 NIGHT-SCOPE Button
(GR-SXM470A/FXM270A/FX220A/
SXM27EA/SX22EA only) ....................... pg. 18
0 REFRESH Button .................................... pg. 6
! EJECT Switch ....................................... pg. 13
@ Close Button ........................................ pg. 13
# •MENU Wheel [–, +] .......................... pg. 22
•BRIGHT Wheel [–, +]
(models equipped with
LCD monitor only) ...................... pg. 14, 30
•TRACKING Wheel [–, +] ................... pg. 31
$ •Snapshot Button [SNAPSHOT]
(GR-SXM470A/FXM270A/FX220A/
SXM27EA/SX22EA only) .................... pg. 18
•5-Second Recording Button [5 SEC. REC]
(GR-FXM170A/FXM17A/FX120A/
FX12A only) ...................................... pg. 17
% •Power Zoom Lever [T/W] .................. pg. 16
•Speaker Volume Control [VOL.]
(models equipped with
LCD monitor only) ............................ pg. 30
^ •Picture Stabiliser Button
[P. STABILIZER] ................................. pg. 16
•Time Base Corrector Button [TBC] ..... pg. 31
& Power Switch
[ , OFF, , ] ...................... pg. 14, 30
* Recording Start/Stop Button.................. pg. 14
( Battery Release Switch
[BATTERY RELEASE] .............................. pg. 6
) Dioptre Adjustment Control ................... pg. 8
Connectors
The connectors q to t are located beneath the
cover.
q S-Video Output Connector [S]
(GR-SXM470A/SXM27EA/
SX22EA only) ....................................... pg. 32
w Audio Output Connector [A] ................ pg. 32
e Video Output Connector [V] ................ pg. 32
r J Terminal/Edit Connector
[JLIP (Joint Level Interface Protocol)/EDIT]
• Connect the editing cable when performing
Random Assemble Editing ( pg. 40 – 43).
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
t DC IN Connector............................... pg. 6, 7
Indicators
y CHARGE Lamp ...................................... pg. 6
u • Power Lamp ..................................... pg. 14
• REFRESH Lamp ................................... pg. 6
Other Parts
i LCD Monitor (models equipped
with LCD monitor only) ................. pg. 14, 15
o Shoulder Strap Eyelets ............................ pg. 8
p Eyepiece
Q Battery Pack Mount ............................... pg. 6
W Viewfinder ............................................. pg. 8
E Speaker (models equipped
with LCD monitor only) ....................... pg. 30
R •Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
• Remote Sensor
(GR-SXM470A only) .......................... pg. 36
T Grip Strap .............................................. pg. 8
Y Microphone......................................... pg. 39
U Video Light
(GR-SXM470A/FXM270A/FX220A/
SXM27EA/SX22EA only) ....................... pg. 17
I Tripod Mounting Socket ......................... pg. 8
To Next Page
