JVC GR-FXM40EK User Manual

2-43 2-44
WF1
IC3501-19
REC 0.34 Vp-p
10 mV/20 µsec/DIV
— ASP —
WF2
IC3501-20
REC 1 Vp-p
20 mV/10 µsec/DIV
WF3
IC3501-21
PB 0.17 Vp-p
5 mV/20 msec/DIV
WF4
IC3501-25
PB 0.88 Vp-p
20 mV/5 msec/DIV
WF1
IC4001-146
REC/PB 1.4 Vp-p
50 mV/20 µsec/DIV
WF2
IC4001-147
REC 0.96 Vp-p
20 mV/20 µsec/DIV
WF3
IC4001-160
REC 0.13 Vp-p
5 mV/20 µsec/DIV
WF4
IC4001-161
REC/PB 0.68Vp-p
20 mV/10 µsec/DIV
— DSP —
WF5
IC4001-168
WF6
IC4001-169
REC 0.88 Vp-p
20 mV/20 µsec/DIV
WF1
IC5201-51
REC/PB 80 mVp-p
5 mV/20µsec/DIV
WF2
IC5201-44
PB 0.15 Vp-p
5mV/5 msec/DIV
— TG/CDS —
WF1
IC4702-9
REC 1.28 Vp-p
PB 1.32 Vp-p
WF2
IC4702-12
WF3
IC4702-15
REC/PB 2.3 Vp-p
50 mV/20 µsec/DIV
REC/PB 1.9 Vp-p
50 mV/20 µsec/DIV
20 mV/20 µsec/DIV
WF1
Q5301-B
EE 0.84 Vp-p
20 mV/20 µsec/DIV
— CCD —
WF1
IC101-109
REC/PB 3.2 Vp-p
0.1V/1 msec/DIV
WF2
IC101-111
REC/PB 3.2 Vp-p
0.1V/5 msec/DIV
WF3
IC101-113
REC/PB 3.2 Vp-p
0.1V/0.2 msec/DIV
WF1
IC1601-14
— CPU —
— V-OUT —
— M.MDA —
REC/PB 3.2 Vp-p
0.1 V/0.2 msec/DIV
WF2
IC1601-49
REC/PB 3.2 Vp-p
0.1 V/5 msec/DIV
WAVEFORMS
PB 2.4 Vp-p
50 mV/20 µsec/DIV
REC 0.15 Vp-p
PB 0.12 Vp-p
5 mV/20 µsec/DIV
