EN 33
A battery is included inside the remote control
at the time of purchase.
Remove the insulation sheet before use.
The remote control uses one lithium battery
(CR2025).
A Infrared Beam Transmitting Window
B ZOOM (T/W) Buttons
Zoom In/Out (墌 pg. 18, 21)
C Up Button
Rotate Button (counterclockwise) (墌 pg. 31)
D Skip Backward Button
E Left Button
F Back Button
G PLAYLIST Button (墌 pg. 42)
H START/STOP Button
I SNAPSHOT Button (墌 pg. 20)
J INFO Button (墌 pg. 37)
K Skip Forward Button
L PLAY/PAUSE Button
M Right Button
N Next Button
O Down Button
Rotate Button (clockwise) (墌 pg. 31)
P INDEX Button
Q DATE Button
Playback Using the Remote Control
Beam Effective Area
NOTE:
The transmitted beam may not be effective or
may cause incorrect operation when the remote
sensor is directly exposed to sunlight or powerful
lighting.
To Reinsert the Battery
Remote Sensor
Effective distance for
indoor use:
5 m
Lock Tab
Pull out the battery holder
by pressing the lock tab.
Buttons and Functions
PLAYBACK
M6E3Asia.book Page 33 Monday, March 13, 2006 3:03 PM
To Next Page
