1-7
SPECIFICATIONS
General
Power : 200~240V, 50Hz
Power consumption : Approx. 12 watts(Energy Saving mode : 3 watts)
Video Head system : Rotary 2heads, helical scanning system
(2HD Model)
Double azimuth 4 heads, helical scanning system
(4HD MONO, 4HD Hi-Fi Model)
Tape speed : 23.39 mm/sec (SP mode)11.69 mm/sec(LP mode)
Tape format : Tape width 1/2” (12.7 mm high density VHS tape)
Maximum recording time : 4 hours in SP mode/8 hours in LP mode (with E-240 tape)
Rewind time : Approx. 150 sec. (with E-180 tape)
Dimensions (W X H X D) : 360 x 94.5 x 270 mm
Weight : 9.0 lbs. (4.0 kg)
Operating temperature : 41°F-95°F (5°C-35°C)
Operating humidity : Less than 80%
Timer : 24 hours display type
Video
Television system : CCIR standard (625 lines, 50 fields)
PAL colour signal
Recording format : PAL B/G (HR-J282EU/J283EU/J582EU/J583EU/J285EU/
J290EU/293EU/J585EU/J590EU/J593EU)
PAL N (HR-J295EK/J595EK)
PAL SECAM-L (HR-J295MS/J595MS)
Input level : VIDEO IN (SCART, RCA type)
1.0 Vp-p, 75 ohm, unbalanced
Output level : VIDEO OUT (SCART type)
1.0 Vp-p, 75 ohm, unbalanced
Signal to noise ratio : More than 43 dBm
Audio
Input level : AUDIO IN (SCART type)
Scart type : -6.0dBm, more than 10kΩ
Output level : AUDIO OUT (SCART, RCA type)
Scart type : -6.0dBm, less than 1kΩ
RCA type : -6.0 dBm, less than 1kΩ
Audio track Mono track & Hi-Fi track
Audio signal to noise ratio : Normal : More than 70 dBm(JIS A filter)
Audio dynamic range : Hi-Fi audio : More than 85 dBm(JIS A filter)
• Design and specifications are subject to change without notice.
:Hi-Fi Model only
