SPECIFICATION
• Specifications shown are for SP mode unless otherwise specified.
• E.& O.E. Design and specifications subject to change without notice.
• Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
• "DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
HR-XVC30US,HR-XVC33US,
HR-XVC33UC
HR-XVC33UM HR-XVS44US,HR-XVS44UC HR-XVS44UJ
GENERAL
Power requirement AC 120 V, 60 Hz AC 110 - 120 V, 50 Hz/60 Hz AC 120 V, 60 Hz AC 110 - 120 V, 50 Hz/60 Hz
Power consumption
Power on 27 W 28 W 26 W
Power off 3.1 W 4.9 W
Temperature
Operating 5°C to 40°C (41°F to 104°F)
Storage -20°C to 60°C (-4°F to140°F)
Operating position Horizontal only
Dimensions (W × H × D) 435 mm × 93 mm × 272 mm
Weight 4.4 kg
Format VHS NTSC standard S-VHS/VHS NTSC standard
Maximum recording time
(SP) 210 min. with ST-210 video cassette
(EP) 630 min. with ST-210 video cassette
VIDEO/AUDIO (VCR deck)
Signal system NTSC colour signal and EIA monochrome signal, 525 lines/60 fields
Recording system DA4 (Double Azimuth) head helical scan system
Signal-to-noise ratio 45 dB
Horizontal resolution 230 lines 230 lines (VHS)/400 lines (S-VHS)
Frequency range 70 Hz to 10,000 Hz (Normal audio) 20 Hz to 20,000 Hz (Hi-Fi audio)
Input/Output
RCA connectors: IN × 1, OUT × 1 RCA connectors: IN × 2, OUT × 1 RCA connectors: IN × 2, OUT × 1
S-Video connectors:IN × 2, OUT × 1
VIDEO/AUDIO (DVD deck)
Signal system NTSC
Applicable disc DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
Audio characteristics DVD:4 Hz - 22 KHz
Frequency response CD:4 Hz - 20 KHz
S/N Ratio 90 dB
Harmonic distortion 0.1%
Wow and flutter Below Measurable Level
Dynamic range 90 dB
Output
Component-Y (RCA) 1.0 Vp-p/75 Ω
Component-PB/PR (RCA) 0.7 Vp-p/75 Ω
Audio (RCA) 2 Vrms, 1 KΩ
Digital Audio (COAXIAL) 0.5 Vp-p/75 Ω,(OPTICAL) -21 dBm to -15 dBm(peak)
TUNER
Tuning system Frequency synthesized tuner
Channel coverage VHF: Channels 2 - 13, UHF: Channels 14 - 69,CATV: 113 Channels
RF output Channel 3 or 4 (switchable; preset to Channel 3 when shipped) 75 Ω, unbalanced
TIMER
Clock reference Quartz
Program capacity 1-year programmable timer/8 programs
Memory backup time Approx. 5 seconds Approx. 3 minutes Approx. 5 seconds
ACCESSORIES
Provided accessories RF cable,Infrared remote control
unit, "AA" battery × 2
RF cable,Infrared remote control
unit, "AA" battery × 2,Conversion
plug
RF cable,S-Video cable (4-pin),
Infrared remote control unit, "AA"
battery × 2
RF cable,S-Video cable (4-pin),
Infrared remote control unit, "AA"
battery × 2,Conversion plug
