JVC hr-xvs30ek Service Manual

1-2 (No.YD002)
SPECIFICATION
Specifications shown are for SP mode unless otherwise specified.
E.& O.E. Design and specifications subject to change without notice.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
"DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems, Inc.
HR-XV3EK, HR-XV31EK,
HR-XV32EK
HR-XV3EX, HR-XV31EX HR-XVS30EK HR-XVS30EX
GENERAL
Power requirement AC 220V - 240V, 50 Hz/60 Hz
Power consumption
Power on 26 W 30 W
Power off 6.0 W
Temperature
Operating 5°C to 40°C
Storage -20°C to 60°C
Operating position Horizontal only
Dimensions (W×H×D) 435 mm × 93 mm × 272 mm
Weight 4.5 Kg 4.4 Kg 4.5 Kg 4.4 Kg
Format VHS PAL standard S-VHS/VHS PAL standard
Maximum recording time
(SP) 240 min. with E-240 video cassette
(LP) 480 min. with E-240 video cassette
(EP) - 720 min. with E-240 video cassette
VIDEO/AUDIO (VCR deck)
Signal system PAL-type colour signal and CCIR monochrome signal, 625 lines/50 fields
Recording system DA4 (Double Azimuth) head helical scan system
Signal-to-noise ratio: 45 dB
Horizontal resolution 250 lines SP/LP: 250 lines (VHS)/400 lines (S-VHS)
EP: 220 lines (VHS)/350 lines (S-VHS)
Frequency range 70 Hz to 10,000 Hz (Normal audio) 20 Hz to 20,000 Hz (Hi-Fi audio)
Input/Output 21-pin SCART connectors: IN/OUT × 1, IN/DECODER × 1
RCA connectors: VIDEO IN × 1, AUDIO IN × 1, AUDIO OUT × 1
21-pin SCART connectors: IN/OUT × 1, IN/DECODER × 1
RCA connectors: VIDEO IN × 1, AUDIO IN × 1, AUDIO OUT × 1
S-Video connector: IN × 1
VIDEO/AUDIO (DVD deck)
Signal system PAL
Applicable disc DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
Audio characteristics DVD:4 Hz - 22 KHz
Frequency response CD:4 Hz - 20 KHz
S/N Ratio 90 dB
Wow and flutter Below Measurable Level
Dynamic range 90 dB
Output
Component-Y - (RCA) 1.0 Vp-p/75 Ω
Component-PB/PR - (RCA) 0.7 Vp-p/75 Ω
Audio (RCA) 2 Vrms, 1 KΩ
Digital Audio -21 dBm to -15 dBm(peak)
TUNER/TIMER(VCR deck)
TV channel storage
capacity
99 positions (+AUX position)
Tuning system Frequency synthesized tuner
Channel coverage VHF : 44.5 MHz - 143 MHz/
143MHz - 470 MHz
UHF : 470 MHz - 862 MHz
VHF : 47 MHz - 89 MHz/
104 MHz - 300MHz/302 MHz -
470 MHz
UHF : 470 MHz - 862 MHz
VHF : 44.5 MHz - 143 MHz/
143 MHz - 470 MHz
UHF : 470 MHz - 862 MHz
VHF : 47 MHz - 89 MHz/
104 MHz - 300 MHz/302 MHz -
470 MHz
UHF : 470 MHz - 862 MHz
Aerial output UHF channels 22 - 69 (Adjustable)
Memory backup time Approx. 10 min.
ACCESSORIES
Provided accessories RF cable, Infrared remote control unit, "R6" battery × 2
