BLOCK
DIAGRAM
@
Fiow
of
signal
from
INPUT-1
with
DUBBING
button
OFF:
JX-S100
Input
Select
Circuit
TV
Monitor
C(KOUTPUT-1
Dubbing
Circuit
©
Flow
of
signal
from
INPUT-1
with
DUBBING
button
ON:
JX-S100
Input
Select
Circuit
TV
Monitor
components)
VCR
1
to
4:
Video
components
Signal
flow
SPECIFICATIONS
Inputs
Output
Monitor
:
4
lines
(Super
VHS
compatible)
:
2
lines
(Super
VHS
compatible,
1
line
is
included
in
INPUT-1)
:
1
line
(Super
VHS
compatible)
Frequency
Response
:
0
—
10
MHz
(video),
0
—
100
kHz
(audio)
Dimensions
Weight
:
436
(W)
x
47
(H)
x
165.5
(D)
mm
(including
knobs
and
feet)
1.5
kg
Design
and
specifications
subject
to
change
without
notice.
JX-S
100(EB)
|
(For
Super
VHS
compatible
(No.
70082)
9
