JVC KD-A305J - Page 26

2 (MA429-R002)
Title Line No.MA429<Rev.001> No.MA429<Rev.002> Description
2.1 Identification method T - 2.1 Identification method
1 - Supported reduction in cost, and board contents was
changed.A set put the following label on is an object.
2 - ILLUSTRATION(ma429_2001.png)
SECTION 5 TROUBLESHOOTING
Title Line No.MA429<Rev.001> No.MA429<Rev.002> Description
5.1 16 PIN CORD DIAGRAM (For
KD-A305, KD-R300, KD-S26)
T 5.1 16 PIN CORD DIAGRAM (For KD-
A305, KD-R300)
5.1 16 PIN CORD DIAGRAM (For KD-
A305, KD-R300, KD-S26)
STANDARD SCHEMATIC DIAGRAMS
Schematic Diagram
Diagram Name No.MA429<Rev.001> No.MA429<Rev.002> Description
Menu Main section Old Main section
Menu CD section Old CD section
Menu LCD & Key control section Old LCD & Key control section
Menu - Main section
Menu - CD section
Menu - LCD & Key control section
Printed Circuit Board
Diagram Name No.MA429<Rev.001> No.MA429<Rev.002> Description
Menu Main board Old Main board
Menu Switch board Old Switch board
Menu LED board Old LED board
Menu - Main board
Menu - Switch board
Menu - LED board
Description of Major ICs
Diagram Name No.MA429<Rev.001> No.MA429<Rev.002> Description
Menu - IC681: KSM-2003TN2M
Menu IC701: MN101E16YFA IC701: MN101E16YFA1
Menu IC1: TEF6606T/V3-X IC1: TEF6606T/V5-X
PARTS LIST
MODEL No. LIST
Model No. No.MA429<Rev.002>
KD-A305J 01
KD-R300J 02
KD-R404UI 03
KD-R405U 04
Model No. No.MA429<Rev.002>
KD-R405UH 07
KD-R405UN 05
KD-R405UT 06
KD-R406U 08
Model No. No.MA429<Rev.002>
KD-R406UH 0B
KD-R406UN 09
KD-R406UT 0A
KD-S26J 0C
General assembly [M1MM]
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
M1MM 2 ------------ GE33323-001A HEAT SINK (Addition) 1 0C
M1MM 2 GE33323-001A GE33323-002A HEAT SINK 1 01,02,03,04,05,06,07,08,09,0A,0B
M1MM 4 ------------ GE33325-003A INSULATOR (Addition) 1 0C
M1MM 15 ------------ GE10242-008A FRONT CHASSIS (Addition) 1 0C
M1MM 15 GE10242-001A GE10242-005A FRONT CHASSIS 1 01,02,03,04,05,06,07,08,09,0A,0B
M1MM 21 GE10243-006A GE10243-011A FRONT PANEL 1 01
M1MM 21 GE10243-005A GE10243-010A FRONT PANEL 1 02,0C
