(MA429-R002) 3
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
M1MM 21 GE10243-007A GE10243-012A FRONT PANEL 1 03,04,05,06,07
M1MM 21 GE10243-008A GE10243-013A FRONT PANEL 1 08,09,0A,0B
M1MM 22 ------------ GE33342-038A FINDER ASSY (Addition) 1 0C
M1MM 31 GE33312-004A GE33312-006A NAVI BTN HI 1 01,02,08,09,0A,0B,0C
M1MM 31 GE33312-003A GE33312-005A NAVI BTN HI 1 03,04,05,06,07
M1MM 35 ------------ GE10244-003A REAR COVER (Addition) 1 0C
M1MM 40 GE40440-001A GE40440-003A LIGHTING SHEET 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
M1MM 41 ------------ GE33872-001A NAME PLATE (Addition) 1 0C
M1MM 49 GE31574-104A GE31574-0A5A UT LABEL 1 0A
M1MM 53 ------------ LV45386-001A R2 INDICATION (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B
M1MM 54 ------------ GE40225-001A CAR STEREO TAG (Addition) 1 0C
M1MM 55 ------------ QYSDSP4014ZA SCREW (Addition) 1 0C
M1MM 56 ------------ GE40282-001A LABEL (Addition) 1 0C
CD mechanism FLM-CD2-1D [MBMM]
Part No.
!
Symbol o
r
<Rev.001> <Rev.002>
Part Name Description Qty Models
MBMM 2 LV36800-001A LV36800-002A LINK ARM 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
MBMM 30 LV44640-001A LV45227-001A RACK SPRING 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
MBMM 51 LV36801-001A LV36801-002A GEAR HOLDER 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
MBMM 57 LV22325-001A LV22325-002A R HOLDER ASSY 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
Mecha control board FLM-CD2-1D [03]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
03 Q101 or ------------ 2SD601A/R/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
03 Q201 or ------------ 2SD601A/R/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
Main board [04]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
! 04 IC1 ------------ TEF6606T/V5-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC161 ------------ BD3700FV-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
! 04 IC301 ------------ TB2926CHQ IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC381 ------------ NJM2160BV-X IC (Addition) 1 01
! 04 IC501 ------------ LA6565-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
! 04 IC521 ------------ MN6627945EE IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC581 ------------ NJM4565E-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
! 04 IC701 ------------ MN101E16YFA1 IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC702 ------------ S-80824CNNB-G-W IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC702 or ------------ IC-PST3424U-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC801 ------------ 74AHCT126PW-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
! 04 IC901 ------------ AN34001A IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 IC981 ------------ NJM2878F4-15-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q341 ------------ IMX9-W PAIR
TRANSISTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q501 ------------ 2SA1705/ST/-T TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q521 ------------ ISA1530AC1/R/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q521 or ------------ 2SA2077-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q781 ------------ RT1P141C-X DIGI
TRANSISTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q781 or ------------ UN2111-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q782 ------------ 2SC3928A/QR/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q782 or ------------ 2SC5845-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q784 ------------ RT1P141C-X DIGI
TRANSISTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q784 or ------------ UN2111-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q785 ------------ RT1P141C-X DIGI
TRANSISTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q785 or ------------ UN2111-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q921 ------------ 2SB1132/QR/-W TRANSISTOR (Addition) 1 03,04,05,06,07,08,09,0A,0B
04 Q922 ------------ RT1N141C-X DIGI
TRANSISTOR
(Addition) 1 03,04,05,06,07,08,09,0A,0B
04 Q922 or ------------ UN2211-X TRANSISTOR (Addition) 1 03,04,05,06,07,08,09,0A,0B
04 Q976 ------------ RT1N141C-X DIGI
TRANSISTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q976 or ------------ UN2211-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 Q977 ------------ ISA1530AC1/R/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
