JVC KD-A305J - Page 33

(MA429-R002) 9
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
04 R905 ------------ NRSA02J-102X MG RESISTOR (Addition) 1 03,04,05,06,07,08,09,0A,0B
04 R906 ------------ NRSA63J-473X MG RESISTOR (Addition) 1 03,04,05,06,07,08,09,0A,0B
04 R971 ------------ NRS181J-332X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 R976 ------------ NRSA02J-273X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 R977 ------------ NRSA02J-123X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L1 ------------ NQL093K-R47X COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L2 ------------ NQL093K-1R8X COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L3 ------------ QQL213M-R22Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L4 ------------ QQR1813-001 COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L5 ------------ QQL244J-561Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L6 ------------ QQL244J-561Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L7 ------------ QQL244K-4R7Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L8 ------------ QQL244K-4R7Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L120 ------------ NQR0007-002X FERRITE
BEADS
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L121 ------------ NQR0007-002X FERRITE
BEADS
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L122 ------------ NQR0007-002X FERRITE
BEADS
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L701 ------------ QQL244K-4R7Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L702 ------------ QQL244K-4R7Z COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L901 ------------ QQR1852-001 CHOKE COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 L901 or ------------ QQR0703-001 CHOKE COIL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 CN501 ------------ QGB2027MD-26 CONNECTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 CN701 ------------ QGZ1601J1-15 CONNECTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 CN901 ------------ QNZ0607-001 CAR
CONNECTOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 J1 ------------ QNB0190-001 ANT TERMINAL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 J321 ------------ QNN0832-001 PIN JACK (Addition) 1 01
04 J321 ------------ QNN0802-001 PIN JACK (Addition) 1 02,03,04,05,06,07,08,09,0A,0B,0C
04 J702 ------------ QNS0283-001 STEERING
REMOTE
(Addition) 1 01
04 J801 ------------ QNZ0095-001 CONNECTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 S701 ------------ QSW0648-001Z TACT SWITCH (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 X1 ------------ QAX0928-001Z CRYSTAL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 X521 ------------ QAX0930-001Z CRYSTAL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 X701 ------------ QAX0667-001Z C RESONATOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
04 X702 ------------ QAX0401-001 CRYSTAL (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
Switch board [05]
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
05 IC601 ------------ NCP5623DTBR2G-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 IC661 ------------ PTC6526LQ-L IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 IC681 ------------ KSM-2003TN2M REMOCON RCV (Addition) 1 0C
05 IC681 ------------ NJL29H380A REMOCON RCV (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B
05 Q601 ------------ 2SC3928A/QR/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q601 or ------------ 2SC5845-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,08,09,0A,0B,0C
05 Q601 or ------------ 2SC5845-X TRANSISTOR (Addition) 1 07
05 Q602 ------------ UNR9211G-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q602 or ------------ DTC114EEB-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q604 ------------ 2SA2174G-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q604 or ------------ 2SA1774/QR/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q605 ------------ UN2222-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q605 or ------------ DTD143EK-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q607 ------------ 2SA2174G-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q607 or ------------ 2SA1774/QR/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q608 ------------ UN2222-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q608 or ------------ DTD143EK-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q610 ------------ 2SA2174G-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q610 or ------------ 2SA1774/QR/-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q611 ------------ UN2222-X IC (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 Q611 or ------------ DTD143EK-X TRANSISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D601 ------------ NSSM065T-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D602 ------------ NSSM065T-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D604 ------------ NSSM065T-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D605 ------------ NSSM065T-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D630 ------------ LHQ974/LM/-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
