JVC KD-A305J - Page 34

10 (MA429-R002)
Part No.
!
Symbol or
<Rev.001> <Rev.002>
Part Name Description Qty Models
05 D631 ------------ LHQ974/LM/-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D632 ------------ LHQ974/LM/-X LED (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D650 ------------ MA8056/M/-X Z DIODE (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D650 or ------------ UDZW5.6B-X Z DIODE (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D661 ------------ MA111-X SI DIODE (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 D661 or ------------ 1SS355W-X DIODE (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C604 ------------ NCB31CK-105X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C650 ------------ NCB31CK-104X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C651 ------------ NBE21CM-106X TA E
CAPACITOR
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C661 ------------ NCB31CK-105X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C662 ------------ NDC31HJ-151X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C663 ------------ NCB31CK-223X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C665 ------------ NCB31CK-104X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C666 ------------ NCB31CK-104X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 C682 ------------ NCB31EK-104X C CAPACITOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R601 ------------ NRSA63J-821X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R602 ------------ NRSA63J-821X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R603 ------------ NRSA63J-122X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R604 ------------ NRSA63J-182X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R605 ------------ NRSA63J-272X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R607 ------------ NRSA63J-392X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R608 ------------ NRSA63J-821X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R609 ------------ NRSA63J-821X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R610 ------------ NRSA63J-122X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R611 ------------ NRSA63J-182X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R612 ------------ NRSA63J-272X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R613 ------------ NRSA63J-103X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R614 ------------ NRSA63F-154X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R615 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R618 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R630 ------------ NRSA63J-271X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R631 ------------ NRSA63J-471X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R634 ------------ NRSA63J-561X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R636 ------------ NRSA63J-222X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R637 ------------ NRSA63J-222X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R638 ------------ NRSA63J-222X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R644 ------------ NRSA63J-751X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R645 ------------ NRSA63J-751X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R646 ------------ NRSA63J-122X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R647 ------------ NRSA63J-122X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R648 ------------ NRSA63J-122X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R649 ------------ NRSA63J-162X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R651 ------------ NRSA63J-102X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R656 ------------ NRS181J-471X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R657 ------------ NRS181J-471X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R658 ------------ NRS181J-751X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R660 ------------ NRS181J-394X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R661 ------------ NRSA63J-102X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R662 ------------ NRSA63J-102X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R663 ------------ NRSA63J-102X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R664 ------------ NRS181J-224X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R665 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R666 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R667 ------------ NRSA63J-101X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R681 ------------ NRSA63J-471X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 R682 ------------ NRSA63J-102X MG RESISTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 CJ601 ------------ QGZ1601K1-15S CONNECTOR (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 J601 ------------ QNS0280-001 3.5 JACK (Addition) 1 0C
05 J601 ------------ QNS0215-001 3.5 JACK (Addition) 1 01,02
05 J601 ------------ QNS0245-001 AUX JACK (Addition) 1 03,04,05,06,07,08,09,0A,0B
05 JS686 ------------ QSW1231-002 ROTARY
ENCODER
(Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 S601 ------------ NSW0124-001X TACT SW (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 S602 ------------ NSW0316-001X TACT SWITCH (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 S603 ------------ NSW0316-001X TACT SWITCH (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 S604 ------------ NSW0316-001X TACT SWITCH (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
05 S605 ------------ NSW0316-001X TACT SWITCH (Addition) 1 01,02,03,04,05,06,07,08,09,0A,0B,0C
