JVC KD-AR470 Service Manual

(No.MA232)1-19
5.2.5 Signal processing section
No sound from either
channel.
Is 9V present at pin 26
of IC161?
Compare the L-ch and
R-ch to locate the
defective point.
Is the sound output from
both channels (L, R)?
YES
NO
Is the audio signal
(including sampling
output components)
output to pins 1 and 7 of
IC581 during playback?
Is the audio signal output
at pin 19 and pin 20 of
IC161 during playback?
Normal
YES
NO
YES YES
NO
Check IC581 and its
peripheral circuits.
NO
Check IC161 and its
peripheral circuits.
YES
Check the power
amplifier IC301.
NO
Is 9V present at pin 10
of IC901?
YES
Check the connections
between pin 26 of IC161
and pin 10 of IC901.
NO
Check IC901 and its
peripheral circuits.
