AUDIO SETTINGS
SOUND EFFECT
SPACE ENHANCE
(Not applicable for FM/AM source and DAB source.)
SMALL/MEDIUM/LARGE : Virtually enhances the sound space.;
OFF :Cancels.
SND RESPONSE LEVEL1 / LEVEL2 / LEVEL3 : Virtually makes the sound more realistic.;
OFF :Cancels.
SOUND LIFT LOW / MIDDLE / HIGH : Virtually adjust the sound position heard from the
speakers.;
OFF :Cancels.
VOL LINK EQ ON :Boosts the frequency to reduce the noice heard from outside the car
or running noise of the tyres.;
OFF :Cancels.
K2 TECHNOLOGY (Not applicable for FM/AM source, DAB source and AUX source.)
ON :Improve the sound quality of compressed music.; OFF :Cancels.
Speaker output settings [SPK/PRE OUT]
(Applicable only if [X ' OVER TYPE ] is set to [2-WAY]) (
19)
Select the output setting for the speakers [SPK/PRE OUT] , based on the
speaker connection method.
Connection via lineout terminals
For connections through an external amplifier. ( 30)
Setting on
[SPK/PRE OUT]
Audio signal through lineout terminal
FRONT REAR SW
REAR/REAR (default) Front speakers output Rear speakers output Subwoofer output
SUB.W/SUB.W Front speakers output L (left): Subwoofer
output
R (right): (Mute)
Subwoofer output
Connection via speaker leads
For connections without using an external amplifier. However, with this
settings you can also enjoy the subwoofer output.
( 30)
Setting on
[SPK/PRE OUT]
Audio signal through rear speaker lead
L (left) R (right)
REAR/REAR Rear speakers output Rear speakers output
SUB.W/SUB.W Subwoofer output (Mute)
If [SUB.W/SUB.W] is selected:
–
[120HZ] is selected in [SUBWOOFER LPF] and [THROUGH] is not available.
–
[POSITION R02] is selected in [FADER] and selectable range is [POSITION
R15]
to [POSITION 00] .
