3-10
Switch board
Block No. [0][2]
R709 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R710 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R711 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R712 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R713 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R714 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R715 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R716 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R717 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R720 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R722 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R725 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R726 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R728 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R734 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R735 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R737 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R739 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R740 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R743 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R744 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R746 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R747 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R748 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R749 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R752 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R753 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R754 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R755 NRSA63J-106X MG RESISTOR 10M
Ω
1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R757 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R763 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R771 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R772 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R773 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
AR360
R774 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
G310
R776 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R801 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R802 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R803 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R804 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R805 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R806 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R808 NRSA63J-331X MG RESISTOR 330
Ω
1/16W J
R809 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R810 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
AR360
R892 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
AR360
R901 QRE142J-102X C RESISTOR 1k
Ω
1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω
1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω
1/8W J
R976 NRSA02J-273X MG RESISTOR 27k
Ω
1/10W J
R977 NRSA02J-123X MG RESISTOR 12k
Ω
1/10W J
L1 QQL244J-4R7Z COIL 4.7uH J
L401 NQL114K-470X INDUCITOR 47uH K
L402 NQL114K-470X INDUCITOR 47uH K
L404 NQL114K-470X INDUCITOR 47uH K
L541 NQL114K-470X INDUCITOR 47uH K
L543 NQL114K-470X INDUCITOR 47uH K
L544 NQL114K-470X INDUCITOR 47uH K
L701 QQL244J-4R7Z COIL 4.7uH J
Symbol No.
Part No. Part Name Description Local
L901 QQR0703-001 CHOKE COIL
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0490-001 PIN JACK
AR360
J321 QNN0519-001 PIN JACK
G310
J801 QNZ0095-001 CONNECTOR
TU1 QAU0312-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X401 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
Q670 2SB624/4/-X TRANSISTOR
Q671 UN2211-X TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 SML-310VT/JK/-X LED
D632 SML-310VT/JK/-X LED
D633 SML-310VT/JK/-X LED
D634 SML-310VT/JK/-X LED
D635 SML-310VT/JK/-X LED
D636 LNJ308G81/1-3/X LED
AR360
D636 SML-310VT/JK/-X LED
G310
D637 LNJ308G81/1-3/X LED
AR360
D637 SML-310VT/JK/-X LED
G310
D638 SML-310VT/JK/-X LED
D639 SML-310VT/JK/-X LED
D640 SML-310VT/JK/-X LED
D641 SML-310VT/JK/-X LED
D642 SML-310VT/JK/-X LED
D643 SML-310VT/JK/-X LED
D644 SML-310VT/JK/-X LED
D645 SML-310VT/JK/-X LED
D646 SML-310VT/JK/-X LED
D647 SML-310VT/JK/-X LED
D648 SML-310VT/JK/-X LED
D649 SML-310VT/JK/-X LED
D650 SML-310VT/JK/-X LED
D651 SML-310VT/JK/-X LED
D652 NSPW310BS/BRS/ LED
D653 NSPW310BS/BRS/ LED
D661 MA111-X SI DIODE
D662 MA8051/M/-X Z DIODE
D681 MA8062/M/-X Z DIODE
C661 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C662 NCS31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C681 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C686 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C687 NCB31HK-223X C CAPACITOR 0.022uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R610 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R611 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
