3-11
Function board
(KD-AR270,G220_J,G323,G324_UI,
G325,326_U,UN,UT,UH)
Block No. [0][3]
Main board(KD-G227_EE)
Block No. [0][4]
R671 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R672 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R681 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R682 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R686 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R687 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R688 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
CJ601 QGZ1601K1-15S CONNECTOR (1-15)
JS686 QSW0976-001 ROTARY ENCODER
S601 NSW0124-001X TACT SW
S602 NSW0124-001X TACT SW
S603 NSW0124-001X TACT SW
S604 NSW0124-001X TACT SW
S605 NSW0124-001X TACT SW
S606 NSW0124-001X TACT SW
S607 NSW0124-001X TACT SW
S608 NSW0124-001X TACT SW
S609 NSW0124-001X TACT SW
S610 NSW0124-001X TACT SW
S611 NSW0124-001X TACT SW
S612 NSW0124-001X TACT SW
S613 NSW0124-001X TACT SW
S614 NSW0124-001X TACT SW
S615 NSW0124-001X TACT SW
S616 NSW0124-001X TACT SW
Symbol No.
Part No. Part Name Description Local
IC501 LA6242H-X IC
Q501 2SA1705/ST/-T TRANSISTOR
C501 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C503 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C504 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31HK-222X C CAPACITOR 2200pF 50V K
C513 NCB31HK-682X C CAPACITOR 6800pF 50V K
C515 NCB31HK-122X C CAPACITOR 1200pF 50V K
C517 NCB31HK-182X C CAPACITOR 1800pF 50V K
C518 NDC31HJ-680X C CAPACITOR 68pF 50V J
R500 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R501 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R502 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R503 NRSA63J-512X MG RESISTOR 5.1k
Ω
1/16W J
R505 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
R506 NRSA63J-303X MG RESISTOR 30k
Ω
1/16W J
R507 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R508 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R509 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R510 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R511 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R512 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R513 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R514 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R515 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R516 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R517 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R518 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R519 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R520 NRS181J-220X MG RESISTOR 22
Ω
1/8W J
R568 NRSA63J-752X MG RESISTOR 7.5k
Ω
1/16W J
R569 NRSA63J-113X MG RESISTOR 11k
Ω
1/16W J
CN502 QGZ2512M1-10 CONNECTOR (1-10)
Symbol No.
Part No. Part Name Description Local
CN503 QGZ2512M1-08 CONNECTOR (1-8)
Symbol No.
Part No. Part Name Description Local
IC161 TDA7419-X IC
IC301 LA4743K POWER IC
IC521 MN6627945EE IC
IC523 SN74LVC2G07V-X LOGIC IC
IC581 NJM4565E-X IC
IC701 LC723783-9D14 IC
IC901 AN80T71 REGULATOR IC
IC981 NJU7772F15-X IC
Q1 RT1N141C-X DIGI TRANSISTOR
Q2 RT1N141C-X DIGI TRANSISTOR
Q4 RT1N141C-X DIGI TRANSISTOR
Q5 2SA1365/F/-X TRANSISTOR
Q6 2SA1530A/QR/-X TRANSISTOR
Q31 2SC3928A/QR/-X TRANSISTOR
Q32 2SC3928A/QR/-X TRANSISTOR
Q301 2SC3928A/QR/-X TRANSISTOR
Q341 KTD1304-X TRANSISTOR
Q351 KTD1304-X TRANSISTOR
Q521 2SA1530A/QR/-X TRANSISTOR
Q781 RT1P141C-X DIGI TRANSISTOR
Q782 RT1P141C-X DIGI TRANSISTOR
Q783 RT1P141C-X DIGI TRANSISTOR
Q902 2SC3928A/QR/-X TRANSISTOR
Q903 2SA1530A/QR/-X TRANSISTOR
D1 1SS355W-X DIODE C.M
D2 1SS355W-X DIODE C.M
D3 1SS355W-X DIODE C.M
D4 1SS355W-X DIODE C.M
D301 UDZW3.3B-X SI DIODE
D341 1SS355W-X DIODE C.M
D351 1SS355W-X DIODE C.M
D501 1A3G-T1 SI DIODE
D703 1SS355W-X DIODE C.M
D706 1SS355W-X DIODE C.M
D711 UDZW6.2B-X SI DIODE
D712 UDZW6.2B-X SI DIODE
D713 UDZW6.2B-X SI DIODE
D714 UDZW6.2B-X SI DIODE
D715 UDZW6.2B-X SI DIODE
D716 UDZW6.2B-X SI DIODE
D717 UDZW6.2B-X SI DIODE
D718 UDZW6.2B-X SI DIODE
D719 UDZW6.2B-X SI DIODE
D720 UDZW6.2B-X SI DIODE
D721 UDZW6.2B-X SI DIODE
D781 1SS355W-X DIODE C.M
D782 UDZW10B-X Z DIODE
D783 1SS355W-X DIODE C.M
D784 1SS355W-X DIODE C.M
D901 1N5401-F64 DIODE
D903 1SS355W-X DIODE C.M
D904 CRS03-W SB DIODE
D905 CRS03-W SB DIODE
C1 NDC31HJ-221X C CAPACITOR 220pF 50V J
C2 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C3 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C4 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C8 NDC31HJ-121X C CAPACITOR 120pF 50V J
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C10 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C11 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C31 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
Symbol No.
Part No. Part Name Description Local
