3-17
Switch board
(KD-G321,G322_E,EX,EY,EU)
Block No. [0][8]
CN701 QGZ1601J1-15 CONNECTOR (1-15)
CN761 QGA2006F1-02 CONNECTOR W-B (1-2)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0773-001 PIN JACK
PP1 QZW0010-001 STYLE PIN
PP2 QZW0010-001 STYLE PIN
S775 QSW1049-001Z TACT SW
TU1 QAU0443-001 TUNER
X71 QAX0263-001Z CRYSTAL 4.332MHz
X521 QAX0714-001Z C RESONATOR 16.000MHz
X701 QAX0667-001Z C RESONATOR 8.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
Q670 2SA1365/F/-X TRANSISTOR
Q671 RT1N141C-X DIGI TRANSISTOR
D630 SML-310LT/MN/-X LED
D631 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D631 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D632 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D633 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D634 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D635 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D635 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D636 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D636 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D637 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D637 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D638 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D638 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
Symbol No.
Part No. Part Name Description Local
D639 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D639 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D640 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D640 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D641 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D641 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D642 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D642 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D643 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D643 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D644 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D644 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D645 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D645 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D646 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D646 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D647 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D647 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D648 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
D648 SML-310VT/JK/-X LED
G322E,G
322EU,G
322EX,G
322EY
D649 LNJ308G81/1-3/X LED
G321E,G
321EU,G
321EX,G
321EY
