3-14
Switch board (KD-G334,G335,G338)
Block No. [0][4]
R595 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R596 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R597 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R701 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R703 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R705 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R706 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R707 NRSA63J-106X MG RESISTOR 10M
Ω
1/16W J
R708 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R710 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R711 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R712 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R713 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R717 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R718 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R719 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R721 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R722 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R723 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R724 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R731 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R732 NRS181J-472X MG RESISTOR 4.7k
Ω
1/8W J
R733 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R734 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R735 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R736 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R737 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R738 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R751 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R752 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R753 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R754 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R755 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R757 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R758 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R761 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R762 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R763 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R764 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R765 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R766 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R767 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R768 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R769 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R770 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R771 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R772 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R773 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R774 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R775 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R779 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R780 NRSA63J-201X MG RESISTOR 200
Ω
1/16W J
R782 NRS181J-473X MG RESISTOR 47k
Ω
1/8W J
R851 NRS181J-103X MG RESISTOR 10k
Ω
1/8W J
R881 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R882 NRSA63J-123X MG RESISTOR 12k
Ω
1/16W J
R883 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R901 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R902 NRSA63J-912X MG RESISTOR 9.1k
Ω
1/16W J
R903 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R911 NRS181J-102X MG RESISTOR 1k
Ω
1/8W J
R976 NRS181J-123X MG RESISTOR 12k
Ω
1/8W J
R977 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R978 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
L1 NQL093K-R12X COIL 0.12uH K
L2 NQL093K-R12X COIL 0.12uH K
L3 QQR1773-001 COIL
L4 QQR1773-001 COIL
L5 QQL244J-561Z COIL 560uH J
L6 QQL244J-561Z COIL 560uH J
L7 QQL244J-4R7Z P COIL 4.7uH J
L8 QQL244J-4R7Z P COIL 4.7uH J
L531 QQL244J-4R7Z P COIL 4.7uH J
L701 QQL244J-4R7Z P COIL 4.7uH J
L702 QQL244J-4R7Z P COIL 4.7uH J
Symbol No.
Part No. Part Name Description Local
L901 QQR1735-001 CHOKE COIL
CN501 QGB2044M1-26 CONNECTOR B-B (1-26)
CN701 QGZ1601J1-12 CONNECTOR (1-12)
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0190-001 CAR ANT JACK
J321 QNN0802-001 PIN JACK
S701 QSW0648-001Z TACT SW
X1 QAX0461-002Z CRYSTAL
X551 QAX0413-001Z CRYSTAL 16.9344MHz
X701 QAX0667-001Z C RESONATOR 8.000MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC661 PT6523LQ-L LCD DRIVER
IC681 RPM7338-V4 RM.RECEIVER
D630 SML-310LT/MN/-X LED
D631 SML-310LT/MN/-X LED
D632 SML-310LT/MN/-X LED
D633 SML-310LT/MN/-X LED
D634 SML-310LT/MN/-X LED
D635 SML-310LT/MN/-X LED
D636 SML-310LT/MN/-X LED
D637 SML-310LT/MN/-X LED
D638 SML-310LT/MN/-X LED
D639 SML-310LT/MN/-X LED
D640 SML-310LT/MN/-X LED
D641 SML-310LT/MN/-X LED
D642 SML-310LT/MN/-X LED
D643 SML-310LT/MN/-X LED
D644 SML-310LT/MN/-X LED
D645 SML-310LT/MN/-X LED
D646 SML-310LT/MN/-X LED
D647 SML-310LT/MN/-X LED
D648 SML-310LT/MN/-X LED
D649 NSPW310BS/BRST/ LED
D650 NSPW310BS/BRST/ LED
D661 1SS355W-X DIODE
D661 or MA111-X SI DIODE
D662 UDZW5.1B-X SB DIODE
D662 or MA8051/M/-X Z DIODE
C661 NCB21AK-105X C CAPACITOR 1uF 10V K
C662 NDC31HJ-681X C CAPACITOR 680pF 50V J
C663 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C682 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R605 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R606 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R607 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R608 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R609 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R610 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R611 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R612 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R613 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R614 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R615 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R630 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R631 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R633 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R635 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R637 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R639 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
R641 NRSA63J-561X MG RESISTOR 560
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
