General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3004-203 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
9 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 GE10079-001A FRONT CHASSIS
12 FSYH4036-098 SHEET
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 GE31033-001A LOCK LEVER
15 FSKW4005-003 TORSION SPRING
16 GE40202-001A
COMPRESSION
SPRING
17 GE31034-001A RLS KNOB
18 GE40156-001A BLIND
19 GE10077-002A FRONT PANEL
20 GE31031-022A FINDER ASSY
21 GE31027-001A POWER BUTTON
22 GE31038-001A VOLUME KNOB
23 GE40218-002A SHEET
24 GE31039-003A SEL BUTTON
25 GE31040-001A RIM LENS
26 FSYH4036-069 SHEET
27 GE31029-001A D.FUNC BTN
28 FSYH4036-069 SHEET
29 GE20161-001A PRESET BUTTON
30 FSYH4036-069 SHEET (x2)
31 GE31024-001A UP/DOWN BTN
32 GE31028-001A SSM BTN
33 GE31025-001A SEARCH BTN
34 GE31026-001A EJECT BUTTON
35 GE31032-001A DETACH BTN
36 GE40202-003A
COMPRESSION
SPRING
37 GE10078-001A REAR COVER
38 VKZ4777-001 MINI SCREW (x4)
39 GE31021-001A LCD CASE
40 GE31022-002A LCD LENS
41 GE31023-001A LENS CASE
42 GE40199-001A LIGHTING SHEET
43 GE40199-002A LIGHTING SHEET
44 GE31213-001A NAME PLATE
45 QLD0299-001 LCD MODULE
46 QNZ0443-001 LCD CONNECTOR
47 QMFZ047-150-T FUSE 15A
48 GE30912-007A REAR BRACKET
49 QYSDST2606Z SCREW 2.6mm x 6mm
50 QYSDST2606Z SCREW 2.6mm x 6mm
51 GE40172-004A IC BRACKET
52 GE40124-002A REG BRACKET
53 GE30854-001A LED HOLDER
54 QAM0544-002 STEERING CABLE
55 FSYH4036-053 SHEET
56 QYSDSF2606Z SCREW 2.6mm x 6mm
