JVC KD-G615 Service Manual

3-15
Switch board (KD-G615_UH2,UN2,U2)
Block No. [0][5]
R714 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R720 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R721 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R722 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R723 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R725 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R726 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R728 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R729 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R730 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R731 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R732 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R734 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R735 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R736 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R737 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R738 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R739 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R740 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R741 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R743 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R744 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R745 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R746 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R747 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R748 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R749 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R750 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R751 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R753 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R754 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R755 NRSA63J-106X MG RESISTOR 10M
Ω 1/16W J
R756 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R757 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R758 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R759 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R763 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R764 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R765 NRS181J-271X MG RESISTOR 270
Ω 1/8W J
R766 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R767 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R770 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R771 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R772 NRSA63J-271X MG RESISTOR 270
Ω 1/16W J
R775 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R776 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R780 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R781 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R783 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R784 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R785 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R787 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R791 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R792 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R793 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R801 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R802 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R803 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R804 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R805 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R806 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R807 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R808 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R810 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R851 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R881 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R882 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R891 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R892 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R893 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R901 QRE142J-102X C RESISTOR 1k
Ω 1/4W J
R902 NRSA02J-912X MG RESISTOR 9.1k
Ω 1/10W J
R903 NRSA02J-472X MG RESISTOR 4.7k
Ω 1/10W J
R904 NRSA02J-221X MG RESISTOR 220
Ω 1/10W J
R971 NRS181J-222X MG RESISTOR 2.2k
Ω 1/8W J
R972 NRS181J-222X MG RESISTOR 2.2k
Ω 1/8W J
 Symbol No. Part No. Part Name Description Local
R976 NRSA02J-203X MG RESISTOR 20k Ω 1/10W J
R977 NRSA02J-822X MG RESISTOR 8.2k
Ω 1/10W J
RA30 NRZ0065-222X NET RESISTOR 2.2k
Ω
L1 QQL244J-4R7Z COIL 4.7uH J
L701 QQL244K-4R7Z COIL 4.7uH K
L702 NQL79GM-4R7X COIL 4.7uH M
L901 QQR1378-002 COIL
CN101 QGB2027M4-22S CONNECTOR B-B (1-22)
CN251 QGA2501C1-03 CONNECTOR W-B (1-3)
CN701 QNZ0605-001 CAR CONNECTOR
CN901 QNZ0611-001 16P CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0489-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SW
TU1 QAU0223-001 TUNER
X31 QAX0616-001Z CRYSTAL 10.250MHz
X701 QAX0617-001Z CRYSTAL 12.500MHz
X702 QAX0401-001 CRYSTAL 32.768KHz
 Symbol No. Part No. Part Name Description Local
IC601 PT6523LQ-L LCD DRIVER
IC602 RPM7338-V4 RM.RECEIVER
Q640 2SB624/4/-X TRANSISTOR
Q641 UN2211-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D608 CL-190UB2-X-X LED
D609 CL-190UB2-X-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D612 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D618 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D640 MA152WK-X SI DIODE
D641 UDZS5.1B-X Z DIODE
D642 MA111-X SI DIODE
D643 MA8062/M/-X Z DIODE
D645 NSPW310BS/BRS/ LED
D646 NSPW310BS/BRS/ LED
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
R601 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R606 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
