JVC KD-G615 Service Manual

3-16
Mechanism control board
(KD-G615_UH2,UN2,U2)
Block No. [0][6]
R608 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R609 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R610 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R611 NRSA63J-272X MG RESISTOR 2.7k
Ω 1/16W J
R612 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R614 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R620 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R621 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R630 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R632 NRSA63J-821X MG RESISTOR 820
Ω 1/16W J
R634 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R636 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R638 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R640 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R641 NRSA02J-181X MG RESISTOR 180
Ω 1/10W J
R642 NRSA02J-331X MG RESISTOR 330
Ω 1/10W J
R643 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R644 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R646 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R648 NRSA63J-331X MG RESISTOR 330
Ω 1/16W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R654 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R655 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R656 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω 1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω 1/16W J
R660 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R661 NRSA02J-391X MG RESISTOR 390
Ω 1/10W J
R670 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R672 NRSA02J-471X MG RESISTOR 470
Ω 1/10W J
R673 NRSA02J-473X MG RESISTOR 47k
Ω 1/10W J
R674 NRSA02J-102X MG RESISTOR 1k
Ω 1/10W J
R691 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R692 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
CN601 NNZ0085-001 CAR CONNECTOR
EN601 QSW1115-002 ROTARY ENCODER
J601 QNS0245-001 AUX JACK
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S613 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC501 TMP91CW12AF5VD9 IC
IC502 BR24L01AFV-W-X IC
IC503 SN74AHCT126PW-X IC(DIGITAL)
IC504 NJU7241F33-X IC
IC571 PCM1753-X IC
IC572 NJM4580V-X IC
IC573 SN74AHCU04PW-X IC
IC601 TA2157FN-X RF AMP IC
IC621 TC94A14FA CD LSI IC
IC651 NJU7772F15-X IC
IC652 TC94A34FG-002 IC
IC681 BA5830FP-X IC
Q501 UN2111-X TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q571 UN2111-X TRANSISTOR
Q572 UN2211-X TRANSISTOR
Q573 2SB624/4/-X TRANSISTOR
Q574 UN2211-X TRANSISTOR
Q601 2SB1132/QR/-W TRANSISTOR
Q651 2SB624/4/-X TRANSISTOR
Q652 UN2211-X TRANSISTOR
Q681 2SB1184/QR/-X TRANSISTOR
D506 MA111-X SI DIODE
D682 1SR154-400-X DIODE
C501 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C502 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C503 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C504 NDC31HJ-220X C CAPACITOR 22pF 50V J
C505 NDC31HJ-220X C CAPACITOR 22pF 50V J
C506 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C507 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C508 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C510 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C511 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C512 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C513 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C514 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C551 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C561 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C571 NDC31HJ-270X C CAPACITOR 27pF 50V J
C572 NDC31HJ-270X C CAPACITOR 27pF 50V J
C573 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C574 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C575 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C577 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C578 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
C580 NCB31EK-123X C CAPACITOR 0.012uF 25V K
C581 NDC31HJ-101X C CAPACITOR 100pF 50V J
C582 NDC31HJ-101X C CAPACITOR 100pF 50V J
C583 NCS31HJ-821X C CAPACITOR 820pF 50V J
C584 NCS31HJ-821X C CAPACITOR 820pF 50V J
C585 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C586 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C587 NDC31HJ-151X C CAPACITOR 150pF 50V J
C588 NDC31HJ-151X C CAPACITOR 150pF 50V J
C589 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C590 NEAG1VM-475X E CAPACITOR 4.7uF 35V M
C591 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C592 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C593 NEAG1CM-476X E CAPACITOR 47uF 16V M
C594 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C595 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C596 NDC31HJ-101X C CAPACITOR 100pF 50V J
C597 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C598 NCS31HJ-102X C CAPACITOR 1000pF 50V J
C601 NEAG0JM-476X E CAPACITOR 47uF 6.3V M
C602 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C603 NEAG0JM-107X E CAPACITOR 100uF 6.3V M
