JVC KD-R460J User Manual

(No.MA596<Rev.005>)10/28
63 TDO O Debugging Interface. Serial Output for Instructions and Data
64 TDI I Debugging Interface. Serial Input for Instructions and Data
65 TMS I Debugging Interface. Test Mode Select Signal Input.
66 TCK I Debugging Interface. Test Clock Input.
67 NC O No Use
68 NC I No Use
69 PVcc - Power supply for I/O circuits
70 SPBCLK O FLASH SPI Multi I/O Bus Clock output
71 Vss - GND
72 SPBSSL O FLASH SPI Multi I/O Bus Slave Select Output
73 SPBIO0 I/O FLASH SPI Multi I/O Bus I/O Data 0
74 SPBIO1 I/O FLASH SPI Multi I/O Bus I/O Data 1
75 SPBIO2 I/O FLASH SPI Multi I/O Bus I/O Data 2
76 Vss - GND
77 SPBIO3 I/O FLASH SPI Multi I/O Bus I/O Data 3
78 Vcc - Power supply
79 MD_CLK I Clock Mode Set (Power ON Reset)
EXTAL Pin Input Clock Ranges from 10 to 12 MHz
80 MD_BOOT I BOOT Mode Set L: Boot mode 0/
H: Boot mode 1
81 DRV_MUTE O Motor Driver Control
81 DEBUG_2C O For Debug
82 PVcc - Power supply for I/O circuits
83 DAB_PON O Control 3..3V power for DAB Module (for DAB model only) H: ON/L: OFF
83 HD_PON O Control 3.3V power for HD module (for HD model only) HD source= H: ON/
Other source= L: OFF
83 NC O No Use (for non DAB/non HD model)
84 Vss - GND
85 MUTE O Muting Output for Evol & Line Out L: Mute ON/H: Mute OFF
86 Vcc - Power supply
87 BT_RST O BT Reset Output (For BT model) L: Reset ON/
H: Reset OFF
87 NC O No Use (for non BT model)
88 PON_DCDC6V O Enable Output for DC-DC Regulator
89 LCD_DATA_LCD I LCD DATA Intput (for LCD Model)
90 DAB_REQ_DAB I Command Request from DAB micon to main micon
90 NC O No Use (for non DAB model)
91 EVOL_SCL I/O I2C Clock 391kHz for E-Vol
91 EP_SCL I/O I2C Clock 391kHz for E2PROM
91 TU_SCL I/O I2C Clock 391kHz for Tuner
92 EVOL_SDA I/O I2C Data for E-Vol
92 EP_SDA I/O I2C Data for E2PROM
92 TU_SDA I/O I2C Data for Tuner
93 IPOD_SCL O iPod Authentication IC I2C Clock Clock speed 23kHz
93 NC O No Use (For non-iPod Model)
94 IPOD_SDA O iPod Authentication IC I2C Data
94 NC O No Use (For non-iPod Model)
95 REG_SCL O I2C Clock for Regulator IC
96 REG_SDA O I2C Data for Regulator IC
Pin No. Pin Name I/O Application
Processing/Operation/
Description
