JVC KD-R856BT User Manual

21
ENGLISH |
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
SPECIFICATIONS
USB
USB Standard USB1.1, USB2.0 (Full speed)
Compatible Devices Mass storage class
File System FAT12/16/32
Maximum Supply Current DC5V
1A
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
WAV Decode Linear-PCM
Bluetooth
Version
Bluetooth Ver.2.1+EDR
Frequency Range
2.402 GHz — 2.480 GHz
Output Power
+4 dBm (MAX), 0 dBm (AVE) Power Class 2
Maximum Communication Range
Line of sight approx. 10 m
Profile
HFP1.5 (Hands-Free Profile), A2DP (Advanced
Audio Distribution Profile), AVRCP1.3 (Audio/
Video Remote Control Profile), OPP (Object
Push Profile), PBAP (Phonebook Access
Profile), SPP (Serial Port Profile)
Audio
Maximum Output Power 50W×4
Full Bandwidth Power
(at less than 1% THD)
22W×4
Speaker Impedance 4Ω—8Ω
Preout Level/Load (CD) 2500mV/10kΩ load
Preout Impedance ≤600Ω
General
Operating Voltage
(10.5V—16V allowable)
14.4V
Maximum Current Consumption 10A
Operating Temperature Range 0°C to +40°C
Installation Size (W×H×D) 182mm×53mm×158mm
Weight
1.26k
g
Subject to change without notice.
TUNER
FM Frequency Range 87.5MHz to 108.0MHz (50kHz step)
Usable Sensitivity
(S/N=26dB)
8.2dBf (0.71μV/75Ω)
Quieting Sensitivity
(DINS/N=46dB)
17.2dBf (2.0μV/75Ω)
Frequency Response (±3dB) 30Hz to 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
AM Frequency Range Band 1 (MW): 531kHz to 1611kHz (9kHz step)
Band 2 (SW1): 2940kHz to 7735kHz (5kHz step)
Band 3 (SW2): 9500kHz to 10135kHz (5kHz step)
11580kHz to 18135kHz (5kHz
step)
Channel Space Selection Band 1: 9kHz
Band 2/3: 5kHz
Usable Sensitivity
(S/N=20dB)
MW: 29dBμ (28.2μV)
SW: 30dBμ (32μV)
CD player
Laser Diode GaAIAs
Digital Filter (D/A) 8 times over sampling
Spindle Speed 500 rpm — 200 rpm (CLV)
Wow & Flutter Below measurable limit
Frequency Response (±1dB) 20 Hz — 20 kHz
Total Harmonic Distortion (1 kHz) 0.01 %
Signal-to-Noise Ratio (1 kHz) 105 dB
Dynamic Range 90 dB
Channel Separation 85 dB
MP3 Decode Compliant with MPEG-1/2 Audio Layer-3
WMA Decode Compliant with Windows Media Audio
Auxiliary

Frequency Response (±3dB) 20Hz—20kHz
Input Maximum Voltage 1200mV
Input Impedance 30kΩ
JS_JVC_KD_R856BT_U_03_EN.indd 21JS_JVC_KD_R856BT_U_03_EN.indd 21 12/9/2013 5:26:32 PM12/9/2013 5:26:32 PM
