16
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
SPK/PRE OUT
Connection via lineout terminals
(
25
)
(For
KD-R961BT
)
Setting
Lineout terminal
FRONT REAR SW
REAR/REAR
Front speakers output Rear speakers output Subwoofer output
REAR/SUB.W
———
SUB.W/SUB.W
Front speakers output L (left): Subwoofer output
R (right): (Mute)
Subwoofer output
(For
KD-R864BT
/
KD-R862BT
/
KD-R861BT
)
Setting
Lineout terminal
REAR/SW
REAR/REAR
Rear speakers output
REAR/SUB.W
Subwoofer output
SUB.W/SUB.W
Subwoofer output
Connection via speaker leads (
25
)
Setting
Rear speaker lead
L (left) R (right)
REAR/REAR
Rear speakers output Rear speakers output
REAR/SUB.W
Rear speakers output Rear speakers output
SUB.W/SUB.W
Subwoofer output (Mute)
If [
SUB.W/SUB.W
] is selected:
– [
HIGH120HZ
] is selected in [
SUB.W
LPF
] and [
THROUGH
] is not available.
– [
R01
] is selected in [
FADER
] and selectable range is [
R06
]to [
00
]
AUDIO SETTINGS
SUB.WPHASE
*
1
REVERSE
(180°)/
NORMAL
(0°):Selects the phase of the subwoofer
output to be in line with the speaker output for optimum performance.
(Selectable only if a setting other than [
THROUGH
] is selected for
[
SUB.W
LPF
].)
HPF
(For
KD-R961BT
)
OFF
:All signals are sent to the front/rear speakers.;
LOW
100HZ
/
MID
120HZ
/
HIGH150HZ
:Audio signals with frequencies lower than
100Hz/ 120Hz/ 150Hz are cut off from the front/rear speakers.
FADER R06
—
F06
(
00
):Adjusts the front and rear speaker output balance.
BALANCE
*
5
L06
—
R06
(
00
):Adjusts the left and right speaker output balance.
VOL
ADJUST –05
—
+05
(
00
):Presets the volume adjustment level of each source
(compared to the FM volume level). Before adjustment, select the source
you want to adjust. (“VOLADJFIX” appears if FM is selected.)
AMP
GAIN LOW
POWER
:Limits the maximum volume level to 30. (Select if the
maximum power of each speaker is less than 50W to prevent damaging
the speakers.);
HIGHPOWER
:The maximum volume level is 50.
D.T.EXP
(Digital Track
Expander)
ON
:Creates realistic sound by compensating the high-frequency
components and restoring the rise-time of the waveform that are lost in
audio data compression.;
OFF
:Cancels.
SPK/PRE
OUT
Selects the appropriate setting to get the desired output.
*
1
Displayed only when [
SUB.W
] is set to [
ON
]. (
15
)
*
2
Displayed only when [
SPK/PRE
OUT
] is set to [
SUB.W/SUB.W
].
*
3
For unit with 3-pair lineout terminals: Displayed only when [
SPK/PRE
OUT
] is set to
[
REAR/REAR
] or [
SUB.W/SUB.W
].
*
4
For unit with 1-pair lineout terminals: Displayed only when [
SPK/PRE
OUT
] is set to
[
REAR/SUB.W
] or [
SUB.W/SUB.W
].
*
5
This adjustment will not affect the subwoofer output.
JS_JVC_KD_R961BT_E_EN_20_1.indd 16JS_JVC_KD_R961BT_E_EN_20_1.indd 16 20/10/2014 11:09:16 AM20/10/2014 11:09:16 AM
