JVC KD-R881BT User Manual

ENGLISH
12
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
• Some Bluetooth devices may not automatically
connect to the unit after pairing. Connect the
device to the unit manually.
• Refer to the instruction manual of the Bluetooth
device for more information.
Auto Pairing
When you connect the following devices to the USB
input terminal, pairing request (via Bluetooth) is
automatically activated.
KD-R981BT / KD-R889BT / KD-R881BT : iPhone/iPod touch/
Android device
KD-R784BT / KD-R782BT : Android device
Press the volume knob (for
KD-R981BT / KD-R784BT /
KD-R782BT ) or (for KD-R889BT / KD-R881BT )
to pair once you have confirmed the device name.
Automatic pairing request is activated only if:
– Bluetooth function of the connected devcie is
turned on.
–
[AUTO PAIRING] is set to [ON] . ( 16)
– JVC MUSIC PLAY application is installed on the
Android device
( 8) and [AUTO MODE] is selected
( 9) .
BLUETOOTH — Mobile phone
Receive a call
When there is an incoming call:
•
KD-R981BT :
The buttons will blink in the color you have selected in
[RING COLOR] . ( 14)
KD-R889BT
/ KD-R881BT :
The symbolic button will blink in the color you have selected in
[RING COLOR] . ( 14)
KD-R784BT / KD-R782BT :
The buttons will blink in the blinking pattern you have selected in
[RING ILLUMI] . ( 14)
• The unit answers the call automatically if [AUTO ANSWER] is set to a selected time. ( 14)
During a call:
•
KD-R981BT :
The buttons stop blinking and illuminate in the color you have selected in
[RING COLOR] . ( 14)
KD-R889BT
/ KD-R881BT :
The symbolic button stop blinking and illuminate in the color you have selected in
[RING COLOR] . ( 14)
KD-R784BT / KD-R782BT :
The buttons stop blinking.
• If you turn off the unit or detach the faceplate, the Bluetooth connection is disconnected.
BLUETOOTH®
KD-R981BT/KD-R784BT/KD-R782BT:
KD-R889BT/KD-R881BT:
Symbolic button
JS_JVC_KD_R981_E_EN_5.indd 12JS_JVC_KD_R981_E_EN_5.indd 12 9/1/2016 2:06:19 PM9/1/2016 2:06:19 PM

JVC KD-R881BT Specifications

General

Audio system	MOS-FET
MP3 playback	Yes
Audio formats supported	FLAC, MP3, WAV, WMA
DIN size	1 DIN
Product color	Black
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Display type	LCD
Display number of lines	2 lines
Key illumination color	Multi
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, PBAP
FM band range	87.5 - 108 MHz
LW band range	153 - 279 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	24

Weight and Dimensions

Weight	1200 g
Dimensions (WxDxH)	182 x 159 x 53 mm
