AUDIO SETTINGS
Determining the value for [DISTANCE] and [GAIN] of [DTA SETTINGS]
If you specify the distance from the center of the
currently set listening position to every speaker, the
delay time will be automatically computed and set.
1 Determine the center of the currently set listening
position as the reference point.
2 Measure the distances from the reference point to
the speakers.
3 Calculate the differences between the distance
of the furthest speaker (rear speaker) and other
speakers.
4 Set the [DISTANCE] calculated in step 3 for
individual speakers.
5 Adjust [GAIN] for individual speakers.
Example: When [FRONT ALL] is selected as the
listening position
*
1
Before making an adjustment, select the speaker:
When 2-way crossover is selected:
FRONT LEFT / FRONT RIGHT / REAR LEFT / REAR RIGHT / SUBWOOFER
– [REAR LEFT] , [REAR RIGHT] and [SUBWOOFER] is selectable only if a setting other than
[NONE] is selected for [REAR] or [SUBWOOFER] of [SPEAKER SIZE] . ( 22)
When 3-way crossover is selected:
TWEETER LEFT / TWEETER RIGHT / MID LEFT / MID RIGHT / WOOFER
– [WOOFER] is selectable only if a setting other than [NONE] is selected for [WOOFER] of
[SPEAKER SIZE] . ( 23)
*
2
Displayed only when [X ' OVER TYPE ] is set to [2-WAY] ( 20) and if a setting other than
[NONE] is selected for [ REAR ] of [SPEAKER SIZE] . ( 22)
DISPLAY SETTINGS
1 Press and hold .
2 KD-R981BT / KD-R784BT / KD-R782BT : Turn the volume knob to select
an item
( 25) , then press the
knob.
KD-R889BT / KD-R881BT : Press to select an item
( 25) , then press .
3 Repeat step 2 until the desired item is selected/activated or
follow the instructions stated on the selected item.
4 Press to exit.
To return to the previous setting item, press .
KD-R981BT:
KD-R889BT/KD-R881BT:
KD-R784BT/KD-R782BT:
Symbolic button
