ENGLISH
30
Data Size: B6L (182 mm x 128 mm)
Book Size: B6L (182 mm x 128 mm)
INSTALLATION/CONNECTION
Symptom Remedy
Bluetooth®
Sound is being interrupted
or skipped during playback
of a Bluetooth audio
player.
•
Reduce the distance between the unit and the
Bluetooth audio player.
•
Turn off, then turn on the unit and try to connect
again.
•
Other Bluetooth devices might be trying to
connect to the unit.
The connected Bluetooth
audio player cannot be
controlled.
•
Check whether the connected Bluetooth audio
player supports Audio/Video Remote Control
Profile (AVRCP). (Refer to the instructions of your
audio player.)
•
Disconnect and connect the Bluetooth player again
“PLEASE WAIT”
The unit is preparing to use the Bluetooth
function. If the message does not disappear, turn
off and turn on the unit, then connect the device
again.
“NOT SUPPORT”
The connected phone does not support Voice
Recognition feature.
“ERROR”
Try the operation again. If “ERROR” appears again,
check if the device supports the function you have
tried.
“H/W ERROR”
Reset the unit and try the operation again. If
“H/W ERROR” appears again, consult your nearest
service center.
If you still have troubles, reset the unit.
( 3)
Warning
•
The unit can only be used with a 12V DC power supply, negative ground.
•
Disconnect the battery’s negative terminal before wiring and mounting.
•
Do not connect Battery wire (yellow) and Ignition wire (red) to the car chassis or Ground wire
(black) to prevent a short circuit.
•
Insulate unconnected wires with vinyl tape to prevent a short circuit.
•
Be sure to ground this unit to the car’s chassis again after installation.
Caution
•
For safety’s sake, leave wiring and mounting to professionals. Consult the car audio dealer.
•
Install this unit in the console of your vehicle. Do not touch the metal parts of this unit during and
shortly after use of the unit. Metal parts such as the heat sink and enclosure become hot.
•
Do not connect the wires of speakers to the car chassis or Ground wire (black), or connect them
in parallel.
•
Connect speakers with a maximum power of more than 50W. If the maximum power of the
speakers is lower than 50W, change the
[AMP GAIN]
setting to avoid damaging the speakers.
( 20)
•
Mount the unit at an angle of less than 30º.
•
If your vehicle wiring harness does not have the ignition terminal, connect Ignition wire (red) to
the terminal on the vehicle’s fuse box which provides 12 V DC power supply and is turned on and
off by the ignition key.
•
Keep all cables away from heat dissipate metal parts.
•
After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are
working properly.
•
If the fuse blows, first make sure the wires are not touching car’s chassis, then replace the old fuse
with one that has the same rating.
Basic procedure
1
Remove the key from the ignition switch, then disconnect the terminal of the car
battery.
2
Connect the wires properly.
See Wiring connection.
( 32)
3
Install the unit to your car.
See Installing the unit (in-dash mounting).
( 31)
4
Connect the terminal of the car battery.
5
Press (for
KD-R981BT
/
KD-R784BT
/
KD-R782BT
) or (for
KD-R889BT
/
KD-R881BT
) to turn on the power.
6
Detach the faceplate and reset the unit.
( 3)
TROUBLESHOOTING
JS_JVC_KD_R981_E_EN_5.indd 30JS_JVC_KD_R981_E_EN_5.indd 30 9/1/2016 2:07:34 PM9/1/2016 2:07:34 PM
