3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3005-001 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
9 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 QYSDSF2006M SCREW 2mm x 6mm(x2)
12 GE30823-001A F. CHASSIS ASSY
13 QYSDST2004M MINI SCREW 2mm x 4mm(x2)
14 FSYH4036-098 SHEET
15 GE30827-002A OPEN LEVER
16 GE30824-002A LOCK LEVER(O.L)
17 GE31245-001A RELEASE LEVER
18 GE30829-001A LOCK LEVER(TOP)
19 GE30825-002A LOCK LEVER(L)
20 GE30828-002A LOCK LEVER(R)
21 GE40154-001A GEAR
22 QZW0108-002 OIL DAMPER
23 FSKW4012-002 T.SPRING
24 VKW5264-005 T.SPRING
25 GE40155-001A T.SPRING
26 QYSDSF2006M SCREW 2mm x 6mm
27 GE40157-001A T.SPRING
28 VKW5263-002 T.SPRING
29 GE40153-001A T.SPRING
30 GE40156-001A BLIND
31 GE10059-010A FRONT PANEL
32 GE20141-017A FINDER LID
SC60
1E,SC
601E
X
32 GE20141-022A FINDER LID
SC60
7EE
33 GE20142-018A FINDER PLATE
34 GE40176-001A SPECIAL SCREW (x2)
35 GE40165-002A SHEET (x2)
36 GE40163-002A REMOTE LENS
37 GE20143-002A PRESET BUTTON
38 GE30810-001A POWER BUTTON
39 GE30915-001A PUSH BUTTON
40 GE30813-202A D.FUNC BTN UP
41 GE30916-002A D.FUNC BTN DOWN
42 GE40124-002A REG BRACKET
43 GE31211-001A NAVI ASSY
44 GE30819-001A NAVI BASE
45 GE40127-002A COMP.SPRING
46 GE31210-001A VOLUME KNOB
47 GE31209-001A SEL BUTTON
48 FSYH4036-053 SHEET
49 GE30817-002A RIM LENS
50 FSYH4036-096 SHEET
51 GE30820-001A EJECT BUTTON
52 VKW3001-330 COMP.SPRING
53 GE30812-001A DETACH BUTTON
54 VKW3001-330 COMP.SPRING
55 GE10060-003A REAR COVER
56 VKZ4777-001 MINI SCREW (x4)
57 GE30821-002A LCD CASE
58 GE30805-001A LCD LENS
59 GE30806-001A LENS CASE
60 GE40150-004A LIGHTING SHEET
61 GE40150-006A LIGHTING SHEET
62 GE31124-001A NAME PLATE
SC60
1E,SC
601E
X
62 GE31289-001A NAME PLATE
SC60
7EE
63 LV41843-002A LASER CAUTION
64 QLD0293-001 LCD MODULE
65 QNZ0442-001 LCD CONNECTOR
66 QAM0419-001 SUB-CABLE
SC60
1E,SC
601E
X
67 QAM0544-002 STEERING CABLE
SC60
1E,SC
601E
X
68 VYTA500-001 PIN CAP (x2)
SC60
1E,SC
601E
X
69 QMFZ047-150-T FUSE 15A
70 GE30912-005A REAR BRACKET
71 QYSDST2606Z SCREW 2.6mm x 6mm(x3)
72 QYSDSF2606Z SCREW 2.6mm x 6mm
73 GE40172-004A IC BRACKET
