Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC161 TEA6320T-X IC
IC251 NJM4565M-WE IC
SC601
E,SC6
01EX
IC252 LC75344M-X IC
SC601
E,SC6
01EX
IC301 LA47515 IC
IC401 TC94A34FG-002 IC
IC461 NJU7772F15-X IC
IC481 AK4385VT-X IC
IC501 LA6579H-X IC
SC601
E,SC6
01EX
IC501 LA6242H-X BTL DRIVER IC
SC607
EE
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC239 IC
SC601
E,SC6
01EX
IC701 UPD784217AGC240 IC
SC607
EE
IC702 IC-PST3433U-X IC
IC771 BR24L32F-W-X IC
IC801 HD74HC126FP-X IC
IC901 HA13164A IC
Q1 2SD601A/QR/-X TRANSISTOR
Q2 2SD601A/QR/-X TRANSISTOR
Q3 UN2111-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q10 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q51 2SD601A/QR/-X TRANSISTOR
Q52 2SD601A/QR/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q81 2SD601A/QR/-X TRANSISTOR
Q84 UN2111-X TRANSISTOR
Q91 2SD601A/QR/-X TRANSISTOR
Q241 2SD601A/QR/-X TRANSISTOR
Q251 UN2111-X TRANSISTOR
SC601
E,SC6
01EX
Q271 2SD1781K/QR/-X TRANSISTOR
SC601
E,SC6
01EX
Q321 2SD1781K/QR/-X TRANSISTOR
Q331 2SD1781K/QR/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q430 UN2211-X TRANSISTOR
Q440 UN2211-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q502 2SB1132/QR/-W TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 UN2111-X TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q543 UN2111-X TRANSISTOR
Q544 2SB624/4/-X TRANSISTOR
Q545 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q841 UN2211-X TRANSISTOR
SC601
E,SC6
01EX
Q881 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SB709A/QR/-X TRANSISTOR
D1 MA111-X SI DIODE
D2 MA111-X SI DIODE
D4 MA111-X SI DIODE
D5 MA111-X SI DIODE
D84 MA111-X SI DIODE
D190 MA111-X SI DIODE
SC601
E,SC6
01EX
D191 MA111-X SI DIODE
SC601
E,SC6
01EX
D192 MA111-X SI DIODE
SC601
E,SC6
01EX
D193 MA111-X SI DIODE
SC601
E,SC6
01EX
D240 MA111-X SI DIODE
D241 MA111-X SI DIODE
D242 MA111-X SI DIODE
D243 RB160M-30-X SB DIODE
D244 UDZS5.1B-X Z DIODE
D272 MA111-X SI DIODE
SC601
E,SC6
01EX
D273 MA111-X SI DIODE
SC601
E,SC6
01EX
D321 MA111-X SI DIODE
D331 MA111-X SI DIODE
D341 MA111-X SI DIODE
D351 MA111-X SI DIODE
D481 UDZS5.1B-X Z DIODE
D701 MA8062/M/-X Z DIODE
D702 MA8062/M/-X Z DIODE
D703 MA8062/M/-X Z DIODE
D704 MA8062/M/-X Z DIODE
D705 MA8062/M/-X Z DIODE
D706 MA8062/M/-X Z DIODE
D707 MA8062/M/-X Z DIODE
D708 MA8062/M/-X Z DIODE
D709 MA8062/M/-X Z DIODE
D710 MA8062/M/-X Z DIODE
D711 MA8062/M/-X Z DIODE
D712 MA8062/M/-X Z DIODE
SC601
E,SC6
01EX
D713 MA111-X SI DIODE
D714 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D715 SML-310VT/JK/-X LED
D716 SML-310VT/JK/-X LED
D717 SML-310VT/JK/-X LED
D718 MA8062/M/-X Z DIODE
D781 MA111-X SI DIODE
D782 MA111-X SI DIODE
D784 UDZS11B-X Z DIODE
D891 MA111-X SI DIODE
D892 MA111-X SI DIODE
D901 1N5401-TU-15 DIODE
D902 MA111-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1HM-104Z E CAPACITOR 0.1uF 50V M
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
