3-11
Front board
Block No. [0][2][0][0]
BZ841 QAN0023-001Z BUZZER
SC601
E,SC6
01EX
CN251 QGA2006C1-04 CONNECTOR W-B (1-4)
SC601
E,SC6
01EX
CN501 QGB2027M4-22S CONNECTOR B-B (1-22)
CN701 QNZ0605-001 CAR CONNECTOR
CN702 QGA2006F1-02 CONNECTOR W-B (1-2)
SC601
E,SC6
01EX
CN901 QNZ0650-001 CAR CONNECTOR
J1 QNB0100-002 CAR ANT JACK
J321 QNN0489-001 PIN JACK
J801 QNZ0095-001 CONNECTOR
PP1 QZW0010-001 STYLE PIN
SC601
E,SC6
01EX
S701 QSW0451-001 DETECT SW
S702 QSW0451-001 DETECT SW
S703 QSW1049-001Z TACT SWITCH
TU1 QAU0313-001 TUNER
SC601
E,SC6
01EX
TU1 QAU0314-001 TUNER
SC607
EE
X31 QAX0776-001Z CRYSTAL
X71 QAX0761-001Z CRYSTAL
X401 QAX0760-001Z CRYSTAL
X701 QAX0777-001Z CRYSTAL
X702 QAX0401-001 CRYSTAL 32.768KHz
Symbol No.
Part No. Part Name Description Local
IC601 LC75823W IC
IC602 RPM7338-V4 REMOCON RCV
Q691 2SD601A/QR/-X TRANSISTOR
Q692 2SD601A/QR/-X TRANSISTOR
Q693 2SD601A/QR/-X TRANSISTOR
Q694 2SD601A/QR/-X TRANSISTOR
D601 SML-310VT/JK/-X LED
D602 SML-310VT/JK/-X LED
D603 SML-310VT/JK/-X LED
D604 SML-310VT/JK/-X LED
D605 SML-310VT/JK/-X LED
D606 SML-310VT/JK/-X LED
D607 SML-310VT/JK/-X LED
D609 SML-310VT/JK/-X LED
D610 SML-310VT/JK/-X LED
D611 SML-310VT/JK/-X LED
D613 SML-310VT/JK/-X LED
D614 SML-310VT/JK/-X LED
D615 SML-310VT/JK/-X LED
D616 SML-310VT/JK/-X LED
D617 SML-310VT/JK/-X LED
D619 SML-310VT/JK/-X LED
D620 SML-310VT/JK/-X LED
D621 SML-310VT/JK/-X LED
D622 SML-310VT/JK/-X LED
D623 SML-310VT/JK/-X LED
D624 SML-310VT/JK/-X LED
D625 SML-310LT/MN/-X LED
D641 UDZS5.1B-X Z DIODE
D643 MA111-X SI DIODE
D646 MA8062/M/-X Z DIODE
D693 SECU2E24C-P-X LED
D695 SECU2E24C-P-X LED
C601 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C602 NCS31HJ-681X C CAPACITOR 680pF 50V J
C603 NBE20JM-106X TA E CAPACITOR 10uF 6.3V M
C611 NCB31HK-123X C CAPACITOR 0.012uF 50V K
Symbol No.
Part No. Part Name Description Local
C612 NBE20JM-475X TA E CAPACITOR 4.7uF 6.3V M
C692 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C693 NCB31HK-103X C CAPACITOR 0.01uF 50V K
R601 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R602 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R603 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R604 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R605 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R606 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R607 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R608 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R609 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R610 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R612 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R613 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R614 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
R615 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R631 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R632 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R634 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R636 NRSA02J-431X MG RESISTOR 430
Ω
1/10W J
R638 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R640 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R642 NRSA02J-431X MG RESISTOR 430
Ω
1/10W J
R644 NRSA02J-271X MG RESISTOR 270
Ω
1/10W J
R646 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R647 NRSA02J-821X MG RESISTOR 820
Ω
1/10W J
R651 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R652 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R657 NRSA63J-513X MG RESISTOR 51k
Ω
1/16W J
R658 NRSA63J-184X MG RESISTOR 180k
Ω
1/16W J
R661 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R662 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R671 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R672 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R673 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R681 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R685 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R686 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R687 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R689 NRSA02J-820X MG RESISTOR 82
Ω
1/10W J
R690 NRSA02J-100X MG RESISTOR 10
Ω
1/10W J
R693 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R694 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R695 NRSA02J-511X MG RESISTOR 510
Ω
1/10W J
R697 NRSA02J-820X MG RESISTOR 82
Ω
1/10W J
R698 NRSA02J-100X MG RESISTOR 10
Ω
1/10W J
CN601 NNZ0087-001 CAR CONNECTOR
EN601 QSW0863-003 ROTARY ENCODER
S601 NSW0206-001X TACT SWITCH
S602 NSW0206-001X TACT SWITCH
S603 NSW0206-001X TACT SWITCH
S604 NSW0206-001X TACT SWITCH
S605 NSW0206-001X TACT SWITCH
S606 NSW0206-001X TACT SWITCH
S607 NSW0206-001X TACT SWITCH
S608 NSW0206-001X TACT SWITCH
S609 NSW0206-001X TACT SWITCH
S610 NSW0206-001X TACT SWITCH
S611 NSW0206-001X TACT SWITCH
S612 NSW0206-001X TACT SWITCH
S614 NSW0206-001X TACT SWITCH
S615 NSW0206-001X TACT SWITCH
S616 NSW0206-001X TACT SWITCH
S617 NSW0206-001X TACT SWITCH
S618 NSW0206-001X TACT SWITCH
Symbol No.
Part No. Part Name Description Local
