KD-SC900R
3-6
Electrical parts list
Main board
Block No. [0][1][0][0]
Symbol No.
Part No. Part Name Description Local
IC31 TB2118F-X PLL IC
IC71 SAA6579T-X IC
IC161 TEA6320T-X IC
IC301 LA4743K POWER IC
IC401 TC94A20F-011 IC
IC461 NJU7241F25-X IC
IC471 NJU7241F33-X IC
IC481 AK4381VT-X IC
IC501 LA6579H-X BTL DRIVER IC
IC521 TA2157FN-X RF AMP IC
IC541 TC94A14FA CD LSI IC
IC581 NJM4565M-WE IC
IC701 UPD784217AGC195 IC
IC702 IC-PST600M/G/-W IC
IC771 BR24L16F-W-X IC
IC901 AN80T07 IC
Q1 2SD601A/R/-X TRANSISTOR
Q2 2SD601A/R/-X TRANSISTOR
Q3 UN2111-X TRANSISTOR
Q5 2SB709A/R/-X TRANSISTOR
Q6 2SB624/4/-X TRANSISTOR
Q7 UN2211-X TRANSISTOR
Q10 UN2211-X TRANSISTOR
Q31 UN2211-X TRANSISTOR
Q51 2SC2412K/R/-X TRANSISTOR
Q52 2SC2412K/R/-X TRANSISTOR
Q53 UN2211-X TRANSISTOR
Q81 2SD601A/R/-X TRANSISTOR
Q84 UN2111-X TRANSISTOR
Q91 2SD601A/R/-X TRANSISTOR
Q241 2SD601A/R/-X TRANSISTOR
Q321 2SD1781K/QR/-X TRANSISTOR
Q331 2SD1781K/QR/-X TRANSISTOR
Q341 2SD1781K/QR/-X TRANSISTOR
Q351 2SD1781K/QR/-X TRANSISTOR
Q430 UN2211-X TRANSISTOR
Q440 UN2211-X TRANSISTOR
Q501 2SB1322/RS/-T TRANSISTOR
Q521 2SB1241/QR/-T TRANSISTOR
Q541 UN2111-X TRANSISTOR
Q542 UN2211-X TRANSISTOR
Q781 UN2111-X TRANSISTOR
Q782 UN2211-X TRANSISTOR
Q784 UN2111-X TRANSISTOR
Q881 UN2211-X TRANSISTOR
Q891 UN2211-X TRANSISTOR
Q976 UN2211-X TRANSISTOR
Q977 2SA1037AK/RS/-X CHIP TR.C.M
D1 1SS355-X SI DIODE
D2 1SS355-X SI DIODE
D4 1SS355-X SI DIODE
D5 1SS355-X SI DIODE
D84 1SS355-X SI DIODE
D240 1SS355-X SI DIODE
D241 1SS355-X SI DIODE
D242 1SS355-X SI DIODE
D243 RB160M-30-X SB DIODE
D244 UDZS5.1B-X Z DIODE
D321 1SS355-X SI DIODE
D331 1SS355-X SI DIODE
D341 1SS355-X SI DIODE
D351 1SS355-X SI DIODE
D501 1A3G-T1 SI DIODE
D701 UDZS6.2B-X Z DIODE
D702 UDZS6.2B-X Z DIODE
D703 UDZS6.2B-X Z DIODE
D704 UDZS6.2B-X Z DIODE
D705 UDZS6.2B-X Z DIODE
D706 UDZS6.2B-X Z DIODE
D707 UDZS6.2B-X Z DIODE
D708 UDZS6.2B-X Z DIODE
D709 UDZS6.2B-X Z DIODE
D710 1SS355-X SI DIODE
D713 UDZS6.2B-X Z DIODE
D714 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D715 LNJ308G81/1-3/X LED
D716 LNJ308G81/1-3/X LED
D717 LNJ308G81/1-3/X LED
D781 1SS355-X SI DIODE
D782 1SS355-X SI DIODE
D784 UDZS11B-X Z DIODE
D891 1SS355-X SI DIODE
D892 1SS355-X SI DIODE
D901 1N5401-F64 DIODE
D902 1SS355-X SI DIODE
D971 RB160M-30-X SB DIODE
D972 RB160M-30-X SB DIODE
C1 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C2 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C3 NCB31EK-103X C CAPACITOR 0.01uF 25V K
C4 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C5 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C6 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C31 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C32 NDC31HJ-470X C CAPACITOR 47pF 50V J
C33 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C34 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C35 NDC31HJ-100X C CAPACITOR 10pF 50V J
C36 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C37 NDC31HJ-100X C CAPACITOR 10pF 50V J
C38 NCB31HK-102X C CAPACITOR 1000pF 50V K
C39 NCB31HK-102X C CAPACITOR 1000pF 50V K
C40 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C41 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C42 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C43 QFV61HJ-473Z MF CAPACITOR 0.047uF 50V J
C44 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C45 NCB31HK-272X C CAPACITOR 2700pF 50V K
C46 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C47 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C48 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C49 NCB31HK-102X C CAPACITOR 1000pF 50V K
C50 NCS31HJ-101X C CAPACITOR 100pF 50V J
C51 NCS31HJ-331X C CAPACITOR 330pF 50V J
C52 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C53 NCB31EK-472X C CAPACITOR 4700pF 25V K
C54 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C55 QEKJ1HM-474Z E CAPACITOR 0.47uF 50V M
C71 NCS31HJ-561X C CAPACITOR 560pF 50V J
C72 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C73 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C74 NDC31HJ-820X C CAPACITOR 82pF 50V J
C75 NDC31HJ-470X C CAPACITOR 47pF 50V J
C76 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C77 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C81 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C82 NCB31HK-152X C CAPACITOR 1500pF 50V K
C83 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C84 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C85 NCB31HK-102X C CAPACITOR 1000pF 50V K
C91 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C92 NCB31HK-152X C CAPACITOR 1500pF 50V K
C94 NCB31HK-123X C CAPACITOR 0.012uF 50V K
C95 NCB31HK-102X C CAPACITOR 1000pF 50V K
C161 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C162 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C164 NCB31HK-822X C CAPACITOR 8200pF 50V K
C165 NCB21CK-184X C CAPACITOR 0.18uF 16V K
C166 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C167 NCB31EK-333X C CAPACITOR 0.033uF 25V K
C168 NCB31HK-562X C CAPACITOR 5600pF 50V K
