JVC KD-SX998R User Manual

KD-SX998R,KD-SX997R
1-8 (No.49819)
2.2 CD Mechanism section
2.2.1 Removing the top cover
(See Figs.1 and 2)
(1) Remove the two screws A on the both side of the body.
(2) Lift the front side of the top cover and move the top cover
backward to release the two joints a.
Fig.1
Fig.2
A
A
A
Joints a
Top cover
Joints a
Top cover
