(No.MA606<Rev.002>)7/20
13 PCB_TEST_MODE
_RX
I PCB Test Mode RX
14 LCD_DATA_SYS O LCD DATA Output (for LCD Model)
14 LCD/
RGB_DATA_SYS
O LCD and RGB DATA Output (for RGB Model)
14 PCB_TEST_MODE
_TX
O PCB Test Mode TX
15 USB_PON O Enable Output for High Side Switch L: HisideSW OFF/
H: HisideSW ON
16 PVcc - Power supply for I/O circuits
17 BT_DATA_BT I BT Data Input (For BT model only)
17 NC O No Use (for non BT model)
18 Vss - GND
19 BT_DATA_SYS O BT Data Output (For BT model only)
19 NC O No Use (for non BT model)
20 Vcc - Power supply
21 PWIC_STBY O Output to Power On Power Amp IC L: Standby/H: Play
22 SXM_DATA_SXM I SXM Data Input (For SXM model only)
22 NC O No Use (for non SXM model)
23 SXM_DATA_SYS O SXM Data Output (For SXM model only)
23 NC O No Use (for non SXM model)
24 DEBUG_1A O For Debug
24 DAB_COM_CLK O Clock to DAB (for DAB model only)
24 HD_SPICLK O Clock to HD Decoder (for HD model only)
25 DEBUG_1B O For Debug
25 DAB_REQ_SYS O Command Request from main micon to DAB micon (for DAB model)
25 HD_REQ_SYS O Command Request from SYS-com to HD (for HD model)
26 DEBUG_1C O For Debug
26 DAB_DATA__SYS O DAB Data Output (for DAB model only)
26 HD_DATA_SYS O HD Data Output (for DAB model only)
27 DAB_DATA_DAB I DAB Data Input (for DAB model only)
27 HD_DATA_HD I HD Data Input (for HD model only)
27 NC O No Use (for non DAB / HD model)
28 PVcc - Power supply for I/O circuits
29 FREQ_SEL O Frequency Select Pulse: Power On/
L: Power Off
30 Vss - GND
31 ENC2 I Volume Encoder Pulse Input 2
32 ENC1 I Volume Encoder Pulse Input 1
33 REMO I Remocon Input L (Pulse): Remote control
data/H: Standby
34 LCD_DATA_LCD I LCD DATA Intput (for LCD Model)
35 MRC_DATA_MRC I Marine REMO Data Input UART 57.6kHz (For MARINE model)
35 DEBUG_2A O For Debug
36 PVcc - Power supply for I/O circuits
37 NC O System Clock Output to External Devices (for LCD Model)
No Use
Pin No. Pin Name I/O Application
Processing/Operation/
Description
To Next Page
